High Precision PCB Punching Machine with Servo Motor Push Pull and Large 400x400mm Working Area for PCB Depaneling

Brand Name: Winsamrt
Model Number: SMTP300
MOQ: 1 set
Price: USD1-10000/set
Packaging Details: Plywood case
Payment Terms: L/C,T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE
Noise:
≤75dB
Working Area:
400x400mm
Output:
25T
Type:
Hydraulic Driven
Precision:
±0.05mm
Name:
25 Ton Output PCB Punching Machine
Supply Ability:
100 sets
Highlight:

Servo Motor Push Pull PCB Punching Machine

,

High Precision PCB Depaneling Machine

,

Large 400x400mm Working Area PCB Separator Punching Machine

Product Description
25 Ton Output PCB Punching Machine with Hydraulic Drive and Servo Motor Push Pull
High-precision depaneling system designed for mass production of PCBs up to 400mm x 400mm, featuring hydraulic drive and servo motor positioning for clean, burr-free separation with minimal mechanical stress.
Key Features
  • 25 Ton Punching Force: High-capacity hydraulic system for clean and efficient depaneling
  • Large Working Area: Supports PCB sizes up to 400mm x 400mm
  • Precision Servo Positioning: High-accuracy servo drive ensures correct alignment
  • Interchangeable Die Sets: Quick-change system for different board formats
  • Heavy-Duty Frame: Rigid structure reduces vibration and enhances accuracy
Technical Specifications
Parameter Value
Driven System Hydraulic station + hydraulic cylinder
Power Supply Phase 3, 380VAC 50HZ
Output Force 25 Ton
Max PCB Size 400×400mm
Working Mode Servo motor push-pull for lower mold
Machine Dimensions 1400×985×1750mm
Weight 850kg
Detailed Specifications
Specification Detail
Working area 400×400mm
Working pressure 0.45-0.7Mpa
Cutting precision ±0.05mm
Cycle time 7-15 seconds
PCB/FPC thickness 0.08-3.5mm
Compatible materials FPC, FR1, FR4, CEM-1, CEM-3, MCPCB
Cutting mode Punching
Punch fixture Die tooling (mold)
Operation features LCD display, automatic product counting, automatic punching
Power requirements 380/220V
High Precision PCB Punching Machine with Servo Motor Push Pull and Large 400x400mm Working Area for PCB Depaneling 0
Operational Advantages
  • High Throughput: One-stroke punching allows simultaneous removal of multiple boards
  • Minimal PCB Stress: Cleaner cuts without bending or cracking components
  • Precision Alignment: Servo-driven push-pull ensures accurate positioning every cycle
  • Large Format Capability: Handles PCBs up to 400×400mm
  • Durable Construction: Hydraulic system offers long-term stability
  • Flexible Tooling: Quick-change die system for different PCB designs
  • Safety Features: Built-in protection for operators and equipment
Tags:

Flex boards PCB Punching Machine
