Automatic Solder Wire Feeding Hot Bar Soldering Machine with LCD Display
  • Name
  • Name

Automatic Solder Wire Feeding Hot Bar Soldering Machine with LCD Display

Brand Name: Winsmart
Model Number: SMTS01
MOQ: 1 set
Price: USD1-10000/Set
Packaging Details: Plywood case
Payment Terms: L/C, T/T, Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE
CE Approval:
Yes
Fixture Quantity:
1
Voltage:
220V/110V
Temperature Accuracy:
±2°C
Thermode Quantity:
1
Control System:
PLC
Display:
LCD
Temperature Range:
50-500℃
Type:
Automatic
Product Name:
Automatic Wire Soldering Machine
Supply Ability:
200 sets per month
Product Description

Automatic Solder Wire Feeding Hot Bar Soldering Machine with LCD Display





Automatic Wire Soldering Machine Introduction:

An Automatic Wire Soldering Machine is a precision device designed to automate the process of soldering wires to PCBs (Printed Circuit Boards). These machines are widely used in electronics manufacturing, automotive wiring harness production, and other industries requiring high-speed and high-quality soldering.





Automatic Wire Soldering Machine Features:

1. Use pulse heating technology, the temperature control is accurate, and the temperature sampling frequency is 0.1s

2. Multi stage temperature rise control, ±2℃ soldering precision

3. Real time temperature curve display

4. High precision soldering, ensures consistent solder joints with accurate temperature and positioning.
5. Automatic wire feeding: feeds and positions wires automatically for efficient operation.
6. Programmable operation: offers customizable soldering patterns, timing, and temperature profiles.



Automatic Wire Soldering Machine Specification:

Machine size 500×500×600mm
Working area Max 200*170mm
Machine weight 62Kg
Working air pressure 0.6-0.8Mpa
Fixture quantity 1
Thermode head size Max 40*3mm
Welding precision pitch 0.2mm
Pressing time 1~99.9s
Temperature settings RT~500℃ tolerance ±5℃
Welding pressure 1~20Kg
Temperature settings Two
Working environment 10-60℃,40%-95%
Power supply AC220V±10% 50HZ,2200W
Alignment mode CCD + LCD Monitor
Feeding mode Manual
Starting mode Press start button
Rotation Platform Cylinder control,tolerance<0.02mm
Thermode material Molybdenum alloy
Thermode size Max 60mm long
Origin China
Fixing mode Customized fixture
Application FFC to PCB, FPC to PCB, Wires to PCB
Warranty 12 months





Automatic Wire Soldering Application:

  • Electronics Manufacturing: For soldering wires to PCB pads, connectors, or terminals.
  • Automotive Industry: Wiring harness assembly and sensor connections.
  • Consumer Electronics: Mobile phones, wearables, and small appliances.
  • Aerospace and Defense: High-reliability solder joints for avionics.
  • Medical Devices: Precision wiring in diagnostic and therapeutic equipment.
  • LED Lighting: Soldering wires to LED modules or drivers.

Automatic Solder Wire Feeding Hot Bar Soldering Machine with LCD Display 0



Tags:

Pitch 0.2mm Hot Bar Soldering Machine

Pulse Heat PCB Bonding Machine

hot bar machine Programmable Soldering
