Stress-free 580mm Blades Pneumatic V-Cut PCB Separator for Metal Core Boards

Pneumatic V-Cut PCB Separator Description:

The 580mm Pneumatic V-Cut PCB Separator is a high-precision machine designed to separate pre-scored (V-grooved) PCBs quickly, cleanly, and without inducing mechanical stress. Using a pneumatically driven circular blade system, this separator ensures smooth operation and prevents damage to sensitive components during depaneling. Its extended cutting length of 580mm makes it ideal for longer PCBs used in LED lighting, displays, and industrial control systems.

Pneumatic V-Cut PCB Separator Features:

Max Cutting Length: 580mm

Blade Type: Precision circular blades

Drive Type: Pneumatic (air cylinder driven)

Operation: Foot pedal or automatic mode

Material Compatibility: FR4, aluminum boards, and copper-based PCBs

Blade Material: High-speed steel or tungsten steel (customizable)

Adjustable Blade Distance: Accommodates various V-groove depths and PCB thicknesses

Safety Features: Protective guard and emergency stop

Pneumatic V-Cut PCB Separator Specifications:

Pneumatic V-Cut PCB Separator Applications:

It is widely used in modern V-score PCB industry, improve cutting effect to avoid component damage.

Please provide below parameters of your panels to confirm if standard machine is workable for your applications:

1. Max component height

2. Min distance between component and v-scoring

3. Max panel length

Support and Services:

The PCB Separator Machine is a high-quality product that is designed to efficiently and accurately separate printed circuit boards. It features a user-friendly interface and is easy to operate. Our technical support team is available to assist with any questions or concerns regarding the installation, operation, and maintenance of the machine. We also offer a range of services to ensure that our customers get the most out of their investment, including training, troubleshooting, and repair services.

Packing and Shipping:

Product Packaging:

• The PCB separator machine will be packaged in a sturdy cardboard box to prevent damage during transportation.
• All necessary accessories and parts will be securely placed inside the box.
• The box will be labeled with the product name and specifications for easy identification.

Shipping:

• The product will be shipped via a reputable courier service to ensure timely and safe delivery.
• Customers will receive a tracking number to monitor the status of their shipment.
• The shipping cost will be calculated based on the customer's location and shipping preferences.
• International customers may need to pay additional customs fees upon receipt of their order.

FAQ:

Q: What is the brand name of this PCB Separator Machine?

A: The brand name of this product is Winsmart.

Q: What is the model number of this PCB Separator Machine?

A: The model number of this product is SMTPD2.

Q: Where is this PCB Separator Machine manufactured?

A: This product is manufactured in China.

Q: Does this PCB Separator Machine have any certifications?

A: Yes, this product is CE certified.

Q: What is the minimum order quantity for this PCB Separator Machine?

A: The minimum order quantity for this product is 1 unit.

Q: Is the price of this PCB Separator Machine negotiable?

A: Yes, the price of this product is negotiable.

Q: What is the packaging method for this PCB Separator Machine?

A: This product is packaged in a Plywood Case.

Q: What is the delivery time for this PCB Separator Machine?

A: The delivery time for this product is 2-7 days.

Q: What are the payment terms for this PCB Separator Machine?

A: The payment terms for this product are T/T.

Q: What is the supply ability for this PCB Separator Machine?

A: The supply ability for this product is 500 Units/Year.
