Full Automatic PCB Depaneling Router Machine with 360 Degree Rotation Gripper and ±0.01mm Cutting Accuracy for 350x350mm PCBs

Brand Name:	Winsmart
Model Number:	SMTIR812
MOQ:	1 Set
Price:	USD20000-80000
Packaging Details:	Plywood case
Payment Terms:	T/T,L/C,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Color:

White

PCB Material:

FR4, Aluminum

PCB Thickness:

0.8-3.0mm

Advantage:

No Fixture Required

Cutting Precision:

±0.05mm

Max PCB Size:

350x350mm

Feature:

Bottom Cutting

Product Name:

Full Automatic PCB Separator

Supply Ability:

100 Sets/Month

Highlight:

full automatic PCB depaneling router

PCB separator machine 360 rotation

PCB router with rotation gripper

Product Description

Full Automatic PCB Separator PCB Router Machine with 360 Degree Rotation Gripper

The inline PCB depaneling router is a fully automated, high-precision PCB separation solution designed for modern SMT production lines. Eliminating the need for custom jigs, this system uses a high-speed spindle and vision-guided routing to depanel PCBs with minimal mechanical stress. Integrated with tray destacking and stacking modules, it offers a complete inline solution for loading and unloading PCBs, ideal for high-mix, high-volume manufacturing environments.

Our Service

Lifetime technical support and 2 years warranty
Free replacement or refund in case of any quality problem
Fast response/feedback within 12 hours
Engineers available for overseas installation and training
Solid packaging to prevent transportation damage

Inline PCB Depaneling Router Features

No-Jig Required Design - Eliminates the need for custom fixtures, reducing setup time and cost
Flexible clamping system - Vacuum table adapts to various PCB shapes and sizes
High-Precision Routing System - High-speed spindle (up to 60,000 RPM) ensures clean, burr-free cuts
Vision alignment system - Fiducial recognition with auto-correction
Inline Conveyor System - SMEMA-compatible design for SMT line integration
Automatic PCB handling - Programmable conveyor width adjustment
Tray Destacker and Stacker - Automatic tray handling for batch processing
Intelligent Control Software - Touchscreen HMI with recipe management
System integration - Optional barcode scanning and MES/ERP connectivity

Inline PCB Depaneling Router Specifications

Model Number	SMTIR812
Machine Size	1060(L)x1356(W)x1570(H)mm
Machine Weight	Approx 1000kgs
Max PCB Size	350x350mm (standard)
PCB Thickness	0.4-6mm
Transmission Height	900±50mm
Transmission Direction	Left -> Right
Transportation Speed	1500mm/s
Feeding Mode	Section type transportation guide rail
Rail Width Adjustment	Automatic
Communication Signal	SMEMA
PCB Positioning	Upper and lower guide rail clamping
Picking System	360 degree rotary clamp system + Vacuum Suction Nozzles
Cutting Spindle	SycoTec 60000rpm/min (standard)
Cooling Type	Self cooling
Automatic Tool Change	Yes
Break Knife Checking	Yes
Cutting Accuracy	±0.01mm
Routing Bit	0.8-3.0 Diameter, right rotation
Repeat Accuracy	±0.02mm
Coordinate Moving Speed	1000mm/s
Unloading Mode	ESD Belt
Waste Collection Way	Outlet track
Procedure Programming	Gerber Drawing Import/Editing Program by Visual
Air Supply	5-8kgs/cm2
Power Supply	AC380V, 50/60Hz, 3KW

PCB Depaneling Router Advantages

No Fixture Cost Saves on fixture design and manufacturing costs, especially for high-mix production.

Stress-Free Depaneling Router-based cutting minimizes mechanical stress and prevents damage to components.

High Flexibility Quickly adaptable to new PCB models or production changes without downtime.

Compact & Fully Automated Minimizes labor and floor space while maximizing throughput.

Reduced Cycle Time Optimized processing for faster production cycles.
