Optional Valve Inline CCD Positioning High Speed Glue Dispensing Machine

Brand Name:	Winsmart
Model Number:	SMTID5X
MOQ:	1 Unit
Price:	Negotiable
Packaging Details:	Plywood Case
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Warranty:

12 Months

Control:

Condition:

100% New

Working Table:

Conveyor Belt

Dispensing Accuracy:

±0.1mm

Rbi Speed:

Continuous RBI 18000 Points /min

Training:

Provided

Power:

2600W

Windows System:

Win 10

Name:

SMT Glue Dispensing Machine

Supply Ability:

500 Units/Year

Highlight:

inline valve glue dispensing machine

high speed smt glue dispenser

CCD positioning glue dispensing machine

Product Description

Optional Valve Inline CCD Positioning High Speed Glue Dispensing Machine

SMT Glue Dispensing Machine Introduction:

This Inline SMT Glue Dispensing Machine is a high-precision, fully automated dispensing machine designed for surface mount technology (SMT) production lines. Integrated with a four-axis motion platform (X, Y, Z, R), a conveyor system, and an advanced CCD vision alignment system, this dispenser ensures accurate and efficient application of adhesives such as red glue, UV glue, or conductive adhesive on PCB boards or other electronic components. It is ideal for high-volume, high-accuracy electronic assembly processes.

Optional Valve Inline CCD Positioning High Speed Glue Dispensing Machine 0

SMT Glue Dispensing Machine Features:

1. CCD visual positioning, no fixtures required, fast dispensing speed.

2. CCD automatically recognizes templates and generates dispensing trajectories.

3. Combines dispensing and handling processes for multiple production lines.

4. Compatible with various dispensing valves and controlling system, easy to operate, easy to learn and use.

SMT Glue Dispensing Machine Applicable Glue:

RTV white silicone, black glue, epoxy resin, UV glue, conductive glue, AB glue, heat dissipation glue, etc.

SMT Glue Dispensing Machine Specification Parameters:

Model	SMTID5X
Automatic Glue Dispenser	Yes
Dispensing Head	360°Rotatable (Optional)
Glue Capacity	2600ml
Dispensing Tilt Angle	180°(Optional)
Glue Detection	Auto(Optional)
Programming	Visual CCD
Axes	4
Working Area	400mm400100mm
Max Moving Speed	1000mm/s
Driven	Servo motor+ball screw
Air Pressure	≥0.65Mpa
Power Rate	1.5KW
Dispensing Valve Quantity	1
Repeatability Accuracy	±0.02mm
Control Mode	IPC + control Card
Y Axis	200mm
Machine Dimension	1200(L)x1400(W)x1650(H)mm
Machine Weight	300kgs

SMT Glue Dispensing Machine Applications:

This inline dispenser is widely used in the electronics manufacturing industry, including:

• SMT Red Glue Dispensing – for component fixation before reflow soldering.

• LED Module & Strip Assembly – for precise application of encapsulants and adhesives.

• Camera Module & FPC Assembly – for micro-dispensing of UV or structural adhesives.

• Consumer Electronics Assembly – smartphones, tablets, wearables, etc.

• Automotive Electronics – for bonding and sealing components in harsh environments.

SMT Glue Dispensing Machine Main Accessories:

Item	Description	Brand	Unit	Quantity	Function	Remark
1	Servo Motor	HeChuan/INOVSNCE	SET	3	XYZ rotation
2	Servo Driver	HeChuan/INOVSNCE	SET	3	XYZ transmission
3	Step Motor	Leisai	SET	1	R transmission
3	Lead Screw	TBI	SET	3	XYZ transmission
4	Guide Rail	HIWIN	SET	3	XYZ transmission
5	Camera	HIK	SET	1	Positioning
6	Lens	HIK	SET	1	Positioning
7	Motion Controller	Winsmart	SET	1
8	Light	Winsmart	PC	1
9	Display	AOC	PC	1	Display
10	Power Supply	MEAN WELL	PC	1
