Full Automatic SMT Glue Dispensing Conformal Coating Machine For 450x450mm PCB

Brand Name:	Winsmart
Model Number:	SMTID2X
MOQ:	1 Unit
Price:	USD25000/Unit
Packaging Details:	Plywood case
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Color:

White

Glue:

Conformal Coating Materials

Working Stroke:

450*450mm

Moving Speed:

800mm/s

Program Mode:

Visual CCD System

Repeatable Precision:

±0.02mm

Axis:

Multi

Name:

Conformal Coating Machine

Supply Ability:

100 Units/Month

Highlight:

Conformal Coating SMT Glue Dispensing Machine

Full Automatic SMT Glue Dispensing Machine

450x450mm SMT Glue Dispensing Machine

Product Description

Full Automatic SMT Glue Dispensing Conformal Coating Machine For 450x450mm PCB

Conformal Coating Machine Overview:

It is an advanced system used for selectively applying protective coatings to printed circuit boards (PCBs) and electronic assemblies. The use of two valves allows for multiple coating strategies in a single pass, improving flexibility and productivity.

Conformal Coating Machine Features:

1. Adopting computer and motion controller, WINDOWS operating system, fault sound and light alarm, and menu display.

2. The programming adopts manual teaching, with simple and fast operation.

3. Integrated steel sports platform ensures smooth operation.

4. Adopting servo motor and ball screw drive.

5. Working precision: 0.02mm.

6. Automatic valve cleaning system.

7. Specialized aluminum alloy track and stainless steel conveyor chain.

8. Equipped with exhaust gas discharge outlet.

9. Equipped with SMEMA interface for communication with other devices.

Conformal Coating Machine Specification:

Item	Parameter	Item	Parameter
Model	SMTID2X	Transmission Height	900±20mm
Dimension	1000×1200×1680mm(L×W×H)	Transmission Speed	2-13m/min
Weight	450kg	Track	aluminum alloy track + stainless steel chain
Controlling	Industrial computer + sports card	Width Adjustment	Auto
Software	Software + Windows10	Adjustment Speed	250mm/min
Programming	Teaching box and keyboard	PCB Rail	≥5mm
Axis	X,Y,Z	Motor Rate	DC24V 69W*2
Driven	Servo motor+ball screw	Communication	SMEMA
Coating Stroke	L450×W450mm	Coating Speed	2～10mm
Z configuration	Atomization valve + needle dispensing valve	Air Supply	0.4Mpa
Tilt Angle	Single 35°	Exhaust air volume requirements	15m³/min
Transmission Direction	L→R or R→L	Power Supply	AC220V 50～60HZ
Max Moving Speed	800mm/S	Power Rate	2kw
Max Component Height	90mm on both sides	Standard Configuration	LED UV detection lamp
Repeat Precision	±0.02mm		LED Light
Track Quantity	1		Waste liquid recycling
Working Direction	L→R or R→L		Electrostatic interface

Conformal Coating Machine Options:

Optional Items(Please tick“√”or“■”)
Function	Parameters
	Volume	Optional Quantity
Coating capacity	10L	■ 1PCS □ 2PCS
	20L	□ 1PCS □ 2PCS
	Imported 1gaL	□ 1PCS □ 2PCS
	Imported 3gaL	□ 1PCS □ 2PCS
Valve Selection	Dispensing valve (DT-10) Dispensing valve (DT-30) Film valve (WJ-H10) Needle type atomizing valve (AW-10) Small spray valve (HP-05) Big spray valve (HP-W30) Rotatable film valve(TU-100L loop) Rotatable film valve(TU-100L non-loop)	□ 1PCS □2PCS ■ 1PCS □ 2PCS □ 1PCS □ 2PCS □ 1PCS □ 2PCS ■ 1PCS □ 2PCS □ 1PCS □ 2PCS □ 1PCS □ 2PCS □ 1PCS □ 2PCS
Additional Functions	1. □ Fixture returning line
	2. □ UPS
	3. □ Pressure regulator
	4. ■ Coating monitoring(10L,20L, 1gaL,3gaL Universal)
	5. □ Coating monitoring(Fiber)1gaL/3gaL used
	6. □ Barcode scanner
	7. ■ Valve cleaning
	8. □CCD system + PCB pressing

Conformal Coating Machine Details:

2 valves can be accommodated in the standard machine.

Conformal Coating Machine Package:

The machine is package in plywood case with vacuum bag inside.
