330mm Linear Blade Pneumatic PCB Depaneling Machine for LED Lighting

Pneumatic PCB Depaneling Machine Introduction:

• Ideal for Rigid Materials: Capable of cutting metal core boards (aluminum, copper) without cracking or damaging the PCB.
• Clean, Precise Cuts: Delivers burr-free edges with minimal deformation, critical for high-quality assemblies.
• Stress-Free Depaneling: Pneumatic mechanism applies controlled force, reducing stress on components and solder joints.
• Fast Operation: Faster than manual methods; suitable for medium to high-volume production.
• Low Maintenance: Simple mechanical design with fewer moving parts — durable and easy to maintain.
• Cost-Effective: More affordable than laser routers or CNC routers for MCPCBs, with lower operating costs.
• Safe and Easy to Use: Ergonomic design, foot pedal or button activation, and safety shields for operator protection.

Pneumatic PCB Depaneling Machine Specification:

Pneumatic PCB Depaneling Machine Applications:

Pneumatic depaneling machines are suitable for a wide range of industries and PCB types, including:

1. LED Lighting Industry

• Separating aluminum-based MCPCBs used in LED strips, modules, and panels.

• Ensures clean edges and prevents damage to LEDs and solder joints.

 2. Automotive Electronics

• Depaneling rigid or semi-rigid PCBs used in lighting, in-vehicle infotainment, ECUs, and sensors.

• Handles metal core boards commonly used in heat-sensitive applications.

3. Consumer Electronics

• Used for smartphones, tablets, and wearables PCBs that require precise depaneling without damage.

• Supports multi-up panel depaneling in production lines.

4. Industrial Control Systems

• Depaneling PCBs used in control modules, sensors, and communication boards.

• Ensures consistent quality even for thicker or high-density boards.

5. Telecom & Networking Equipment

• Efficiently separates boards with delicate RF components, connectors, and high-density assemblies.

6. Power Supply Units & Converters

• Suitable for high-current boards that are often mounted on metal core substrates.

• Maintains mechanical stability with minimal flexing or cracking.

 7. Medical Devices

• Ideal for small, precision medical PCBs where component safety is critical.

• Clean and burr-free depaneling helps meet strict quality standards.

Looking for a reliable and efficient solution for separating PCB panels? Look no further than Winsmart's SMTPD2 PCB Depaneling Machine. Our high-quality machine is designed to meet your specific needs and requirements, providing you with a customizable service that will help improve your production process.

Our machine, also known as the Inline V-cut PCB Separator, is manufactured in China and is perfect for cutting a wide range of PCB materials, including MCPCB, FR4, and CEM. Its linear blade design ensures precise and clean cuts, making it suitable for both small and large-scale production.

With a cutting capacity of 600mm, our machine is suitable for a variety of PCB sizes, allowing you to efficiently and effectively separate your panels with ease. It is also CE approved, ensuring its safety and quality.

As a leading Inline V-cut PCB Separator manufacturer and Inline PCB Depaneling Machine supplier, Winsmart is committed to providing our customers with top-of-the-line products and excellent customer service. Contact us today to learn more about our customizable services and how we can help improve your PCB production process.
