New Condition Semi Automatic Soldering Machine With Manual Controls

New Condition Semi Automatic Soldering Machine With Manual Controls
New Condition Semi Automatic Soldering Machine With Manual Controls

Large Image :  New Condition Semi Automatic Soldering Machine With Manual Controls

Product Details:
Place of Origin: Chia
Brand Name: Winsmart
Certification: CE
Model Number: SMTSR1
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: 1-2000USD
Packaging Details: Plywood case
Delivery Time: 3-5 working days
Payment Terms: T/T, Western Union
Supply Ability: 500 units/month

New Condition Semi Automatic Soldering Machine With Manual Controls

Soldering Head: 1 Condition: New
Application: Wire To PCB Soldering Solder Wire: 0.6-1.6mm
Service: Yes Welding Pressure: 4-6KG
Customized Jig: Yes Control System: PLC
High Light:

Semi Automatic Soldering Machine


Manual Semi Automatic Soldering Machine


Semi Automatic Robotic Soldering Machine

New Condition Semi-automatic Soldering Machine with Manual Controls

Product Description:

Semi-automatic PCB soldering machine working steps:

1. Plug in the power supply and the air supply.

2. Parameter Setting

(1) Set tin feeding length (length>1mm)

(2) Set tin return length (length>1mm)

3. Speed (speed 1000-2500)

4. Press the reset key for three seconds to reset the output.

5. Press the blank of the parameter page for three seconds, input password “10086” to enter the program interface.

6. Press the blank of self-locking function (manual screen), input password “10086” to set new password by yourself. Specific steps for installing the heater:

(1) Insert the soldering iron into the heating tube

(2). Align the notch mark of the soldering iron head with the direction of the tin feeding tube, tighten the nut knob with a pointed nose pliers, perform daily maintenance every shift, and clean the machine surface

7. Before starting the machine, check whether the soldering head is perforated and oxidized. Before starting the machine, check whether the soldering head moves up and down smoothly. If the tin wire is insufficient, replace it with a new roll of tin wire. If the tin wire tube is blocked, clean it with alcohol.

8. Please use copper brush and alcohol to clean the solder wire powder and flux in time.

9. Ensure sufficient air pressure (0.4-0.5MPa)

10. Check whether the connecting cables are loose and fall off, and whether the air pipe is damaged.

11. Daily maintenance of the soldering head, properly increase the number of times to clean the soldering head.

12. Completely remove the tin material pre welded by the soldering head, cool it to room temperature, remove the oxide with sandpaper, and then restart the heating

13. If the soldering iron head is corroded by oxide, replace it with a new one.


  • Soldering speed: fast and manual control
  • Soldering Speed: 400-500 Points Per Hour
  • Welding Pressure: 4-6KG
  • Status: 100% New
  • Dimension: 400x400x450mm
  • Soldering Head: 1
  • Product Type: Semi-auto PCB Soldering Machine
  • Automation Level: Semi-automatic
  • Soldering Type: Wire Soldering
  • Precision Level: High

Technical Parameters:

Model SMTSR1
Dimension 40x40x45cm
Weight 20Kg
Control PLC
Power supply 220V, 50Hz
Air supply 4-6kgs
Power Rate 160W
Ambient temperature 0-50℃
Ambient humidity 0-70%
Soldering speed 400-500 points/hour


Suitable for switch, led lamp, terminal, sensor, thermistor, aviation head and printed circuit boards and wires soldering.

New Condition Semi Automatic Soldering Machine With Manual Controls 0


Why Choose Winsmart SMTSR1?

The Winsmart Robotic Soldering Machine offers a combination of high-quality soldering, advanced technology, and user-friendly design, making it the perfect solution for any industrial production line. It is a reliable and efficient choice for precision soldering, allowing for a smooth and seamless production process. Invest in the Winsmart SMTSR1 and experience a cost-effective and effortless soldering process for your electronic production needs.


Packing and Shipping:

Packaging and Shipping for Robotic Soldering Machine

The Robotic Soldering Machine will be packaged in a sturdy cardboard box to ensure safe transportation. The machine will be securely placed and protected with foam inserts to prevent any potential damage during shipping.

The box will also include the necessary user manuals and safety instructions for the product.


The shipping of the Robotic Soldering Machine will be done through a reputable shipping company to ensure timely and safe delivery.

The estimated shipping time will be provided to the customer upon purchase and may vary depending on the destination.

For international shipments, all necessary customs and duties will be handled by the shipping company.

Once the product is shipped, the customer will receive a tracking number to track the shipment and stay updated on its delivery status.

Thank you for choosing our Robotic Soldering Machine. We hope it will meet all your soldering needs with its advanced technology and high-quality performance.
