Manual PCB Depaneling Tool Overview:
The Air Driven 200mm Linear Blade Manual PCB Depaneling Tool, also known as a PCB Guillotine, is a manual cutting tool specifically designed for separating individual PCBs from a larger panel. This tool utilizes an air-driven linear blade mechanism to cut through the PCB material with precision and efficiency. It is commonly used in PCB manufacturing and assembly processes to ensure clean and accurate depaneling.
Manual PCB Depaneling Tool Features:
No Power Required: The machine operates without the need for external power, making it highly portable and easy to use in various locations without the constraints of power availability.
V Cut Separation: The machine utilizes a V-cut method to separate metal core PCBs. The V-cut mechanism creates a precise and clean separation along the predefined cut lines, ensuring minimal stress on the PCB and components.
Compact Design: The machine is designed to be compact and lightweight, allowing for easy transportation and space-saving in manufacturing environments.
Adjustable Cutting Depth: The machine offers adjustable cutting depth settings, allowing for customization based on the specific metal core PCB thickness, ensuring optimal cutting performance.
Simple Operation: The machine features user-friendly controls and a straightforward operation process, making it easy for operators to set up and use without the need for extensive training.
Durable Construction: The machine is built with sturdy materials to ensure durability and long-term reliability in demanding manufacturing environments.
Manual PCB Depaneling Tool Performance:
The Air Driven 200mm Linear Blade Manual PCB Depaneling Tool offers several performance advantages:
Precision Cutting: The air-driven linear blade mechanism provides controlled and precise cutting, resulting in clean and accurate separation of PCBs. This ensures high-quality depaneling and minimizes the need for additional rework or touch-up.
Efficiency: The tool allows for efficient depaneling of PCBs, reducing manual effort and time required for separating individual boards from a larger panel. It contributes to increased productivity in the PCB manufacturing process.
Versatility: The adjustable cutting length feature enables the tool to handle various PCB sizes and shapes. It offers versatility in depaneling different types of PCBs, including single-layer, double-layer, and multi-layer boards.
Cost-Effectiveness: The manual operation of the PCB Guillotine eliminates the need for complex machinery or power supply, making it a cost-effective solution for PCB depaneling. It is suitable for both small-scale and large-scale operations.
Manual PCB Depaneling Specification:
|Max Cutting Length
|FR4, MCPCB, CEM, Copper Boards
|High Speed Steel
|Ex-work, FOB, CIF, DDU, DDP
Manual PCB Depaneling Applications:
LED Lighting: Metal core PCBs are commonly used in LED lighting applications. This machine efficiently separates metal core PCBs used in LED lighting fixtures without damaging the sensitive LED components.
Power Electronics: Metal core PCBs are utilized in power electronics applications, such as inverters, motor drives, and power supplies. This machine offers a reliable and efficient solution for depaneling these specialized PCBs.
Automotive Electronics: The machine is applicable in the automotive industry, where metal core PCBs are used in electronic control units (ECUs), lighting systems, and other automotive electronics.
Industrial Electronics: Metal core PCBs find use in industrial control systems, robotics, and automation equipment. The machine enables precise and stress-free separation of metal core PCBs in these applications.
