|Thermode Cooling:||Air||Power Consumption:||500W|
|Fixture Quantity:||2||Product Name:||Hot Bar Soldering Machine|
Flex Rigid PCB Soldering Machine,
220V Hot Bar Soldering Machine,
PCBs Hot Bar Soldering Machine
Pulse Heat Technology Hot Bar Soldering Machine for Flex-Rigid PCB
Pulse Heat Hot Bar Soldering Machine Introduction:
The Pulse Heat Technology Hot Bar Soldering Machine is an advanced equipment designed specifically for soldering flex-rigid PCBs. It utilizes pulse heat technology, along with the integration of a CCD camera, to achieve precise and reliable soldering results. This machine is ideal for applications that require high accuracy and consistency in soldering flex-rigid PCBs.
Pulse Heat Hot Bar Soldering Machine Features:
1. Pulse Heat Technology: The machine utilizes pulse heat technology, which delivers controlled and precise heat pulses to the soldering area. This technology ensures efficient heat transfer, minimizing the risk of damage to delicate flex-rigid PCBs.
2. CCD Camera Integration: The machine is equipped with a CCD camera system that provides real-time visualization and monitoring of the soldering process. The camera allows operators to precisely align components and verify solder joint quality, ensuring accurate and reliable soldering results.
3. Programmable Parameters: The machine offers programmable parameters for temperature, pulse duration, pressure, and other soldering parameters. This feature allows for customization and adaptability to various soldering requirements.
4. Precise Alignment and Pressure Control: The machine incorporates mechanisms for precise alignment of components and controlled application of pressure during soldering. This ensures proper contact between the flex-rigid PCB and the components, resulting in reliable solder joints.
5. User-Friendly Interface: The machine features a user-friendly interface that allows operators to easily set and adjust soldering parameters, monitor the soldering process, and access various functions and settings. The interface enhances ease of use and efficiency.
Hot Bar Soldering Machine Specification:
|Working area||Max 150*150mm|
|Working air pressure||0.6-0.8Mpa|
|Thermode head size||Max 40*3mm|
|Welding precision||pitch 0.2mm|
|Temperature settings||RT~500℃ tolerance ±5℃|
|Power supply||AC220V±10% 50HZ,2200W|
|Alignment mode||CCD + LCD Monitor|
|Starting mode||Press start button|
|Rotation Platform||Cylinder control,tolerance<0.02mm|
Hot Bar Soldering Machine Advantages:
1. High Accuracy and Consistency: The pulse heat technology and CCD camera integration ensure precise alignment, controlled heat transfer, and consistent soldering results. This leads to high-quality solder joints and improved overall product reliability.
2. Damage Prevention: The machine's pulse heat technology minimizes the risk of damage to delicate flex-rigid PCBs by delivering controlled and localized heat pulses. It helps protect the components and the PCB substrate from excess heat exposure.
3. Real-Time Monitoring: The integrated CCD camera provides real-time visualization and monitoring of the soldering process. This allows operators to detect any issues or defects promptly, ensuring immediate corrective actions and reducing the chances of rework.
4. Customizable Parameters: The machine's programmable parameters offer flexibility and adaptability to various soldering requirements. Operators can fine-tune the temperature, pulse duration, pressure, and other parameters to achieve optimal soldering results for different flex-rigid PCB designs.
5. Enhanced Efficiency: The machine's user-friendly interface, precise alignment mechanisms, and advanced soldering technologies contribute to improved efficiency in the soldering process. It reduces production time, minimizes errors, and increases overall productivity.
6. Quality Assurance: The integration of CCD camera monitoring and precise soldering control ensures consistent and reliable solder joint quality. This leads to improved product quality and reduces the risk of soldering-related failures or issues.
Hot Bar Soldering Machine Application:
FFC to PCB soldering
Hot Bar Soldering Machine Thermode:
