Product Details:
|
| PCB Material: | FR4 & MCPCB | PCB Length: | 1200mm |
|---|---|---|---|
| Voltage: | 220V/110V | Multi-blade: | 2-20 Sets |
| PCB Width: | 220mm(Standard) | Name: | Aluminum PCB Cutting Machine |
| High Light: | Aluminum PCB Depanelizer Machine,1200mm LED Boards PCB Depanelizer,LED Boards PCB Depanelizer |
||
Aluminum PCB Cutting Machine 1200mm LED Boards PCB Depanelizer
Aluminum PCB Cutting Machine Features:
It can cut many boards with multiple sets of knives work at the same time.
The distance between knives is regulable as well, satisfy to cutting the single PCB width from 15mm-20mm.
The blade is made of Japan imported high speed and high precision steel material, which is durable and have a long service life.
It is convenient to adjust the cutting speed through rotary knob.
Suitable for 1200mm long boards, and 0.8-3.5mm thick boards.
With a conveyor belt line, the separated PCB can be send out directly to reduce pick- and-place.
The machine adopts multiple blade to separate boards with simple operation and high efficiency.
Feeding track and flat belt is adjustable according to different applications.
Aluminum PCB Cutting Machine Specification:
| Max cutting length | No limit |
| Min cutting length | 100mm |
| Max panel width | 220mm |
| Custom cutting width | 320mm |
| Min PCB width | 8mm |
| PCB thickness | 0.8-3.5mm |
| Feeding speed | 0-500mm/s |
| Working tem. | 10-35℃ |
| Blade material(auto-lock function) | Imported high precision steel |
| Storge tem. | -20-50℃ |
| Voltage | 110-220V |
| Dimension | 2160*570*1050mm |
Aluminum PCB Cutting Machine Advantages:
1. Large LCD Display
2. Regular Wiring
3. Durable ESD Feeding Conveyor Belt
4. Separate 2-20 PCBs at the same time
5. It works for both FR4 and MCPCB boards
6. Suitable for high volume production
7. Connect PCB loader for inline SMT production
