Product Details:
|
| Warranty: | 12 Months | Control: | PC |
|---|---|---|---|
| Belt Width: | 350mm | Axis: | X, Y, Z, R |
| Program Mode: | Visual CCD System | Repeatable Precision: | ±0.02mm |
| On-site Training: | Provided | Name: | Online Glue Dispensing Machine |
| High Light: | R Axis Glue Dispensing Machine,360Deg Axis Glue Dispensing Machine,ESD Conveyor Belt Glue Dispenser |
||
ESD Conveyor Belt Online Glue Dispensing Machine With 360 Degree R Axis
Online Glue Dispensing Machine Application Area:
Power adapters, speakers, power devices, toys, automotive electronics, e-cigarettes, badges, furniture, packaging boxes, white appliances, etc.
Online Glue Dispensing Machine Applicable glue:
Silicone, epoxy resin, UV adhesive, conductive adhesive, AB adhesive, heat dissipation adhesive, etc
Online Glue Dispensing Machine Features:
● The entire series of products adopt visual positioning and following technology, without the need for product fixtures, and the assembly line does not stop working.
● Working mode of online dispensing, combining product dispensing and handling processes, can adapt to multiple production lines.
● The new embedded model can be used as you go along with the solid line, flexible layout, to meet the needs of flexible production.
● Suitable for various dispensing valves and glue supply systems, easy to operate, easy to use and operate.
Online Glue Dispensing Machine Specification:
| Model | SMTID2X |
| Working Stroke | 410x350x100mm |
| Moving Speed | 800 mm/sec |
| Conveyor Belt Speed | 200 mm/sec |
| Driven Mode | (Stepping + belt) or (servo + screw rod) |
| Program Mode | Visual CCD System |
| Repeatable Precision | ±0.02mm |
| OS | Windows 10 |
| Valve Quantity | 1 |
| Warranty | 1 year |
| Glue Packaging | Up to client's requirement |
| Transport height | 900±20mm |
| Transport direction | L→R(R→L Optional) |
| Driven Type | Pneumatic |
| Precision | High |
| Certification | CE |
| Condition | New |
| Nozzle | Optional |
| Air Pressure | 0.7MPa |
| Power | 220V, 1100W |
| Dimension (W*D*H) | 1400x750x1730mm |
| Weight | 280kgs |
Online Glue Dispensing Machine Parameters:
Outer dimension L/W/H : 1400*750*1730(mm)
Workspaces: X 410mm Y350mm Z100mm
Maximum movement speed: 500mm/s
Input speed: 0-200mm/s
Loading weight: Z 8KG Conveyor belt 30KG
Weitht: 300KG
Control of operation: Motion card
Program: PC
Belt driven: Closed-loop stepper motor
Repetitive accuracy ± 0.02mm
Recognition accuracy 0.15mm
Input voltage AC220/50-60HZ
Working pressure 0.7Mpa
Equipment power 1100W
