PCB Glue Dispensing Machine Overview:

PCB gule Dispensing machine in addition to complete the work of precision dispensing, it can also be through the control of its dispensing path for dispensing, if with different colors of glue, then dot glue out of the pattern also has a beautiful effect. There are many problems to be aware of when using PCB automatic dispensing machine to automate dispensing. The first is the viscosity of the glue problem, glue viscosity is not enough will cause the package bonding is not firm, glue ratio is too large and there will be the phenomenon of drawing trailing. Secondly, the elimination of glue bubbles is also a compulsory course before packaging operations, the need for operators and packaging equipment technology to work together. At present, the PCB automatic dispensing equipment on the market has been able to solve this problem very well.



PCB Glue Dispensing Machine Features:

This machine is computer control with CCD visual positioning system, which is suitable for precise dispensing and coating.

We also use high quality parts to build the machine to ensure reliability and accuracy.

Standard machine adopts servo motor and screw drive, with muli-axis design.

Dual tables to improve capacity for high volue production.

It is used pneumatic injection/piezoelectric/screw/AB rubber valve, according to different dispensing materials.

The desktop design has small footprint.

The most important is that machine cost is economic.

1. Adopting computer control, Windows operating system, fault sound and light alarm, and menu display



PCB Glue Dispensing Machine Specification:

Model SMTDR6

Working area

X/Y/Z(mm)

200*400, Dual Tables

Max load

Y-axis/Z-axis

10kg/5kg

Moving speed

X&Y/Z(mm/sec)

0.1-800/500
Relolution 0.01mm/Axis
Repeatability ±0.01mm/Axis
Program capacity No Limit
Data storage type PC Windows 10
Coating Capacity 30CC
Display LCD
Number of axis 4
Programming method Visual programming
Valve nozzle cleaning device Optional
Valve Different valves are available for different applications
Warranty 1 year
Tables 2
OS Windows 10
Software Friendly
Programs No limit
Camera Yes
Power AC110V/220V
Working tem. 5-50℃
Power Rate 2.5KW
Air pressure ≥ 0.65Mpa
valve quantity 1(standard)
Working Humidity 20-90% no condensation

Dimension

(W*D*H)mm

950*850*850
Weight(Kg) 150



PCB Glue Dispensing Machine Dispensing Material:
Anaerobics, Coatings, Cyanoacrylates, White Glues, Epoxy Resin, Greases, Sealants, Silicones, Solder/Braze Pastes, Thermal Grease, Conductive Adhesive, Red Gum, UV Glue, AB Glue, Polyurethane Resin Adhesive, etc.
