Product Details:
|
| Driven: | Pneumatic | Testing Report: | Provided |
|---|---|---|---|
| Working Stroke: | 200*300mm(Dual Tables) | Max Loading: | 8kgs |
| Program Mode: | PC | Repeatable Precision: | ±0.05mm |
| Axis: | Multi | Name: | SMT Dispenser |
| High Light: | Desktop SMT Dispenser,Dual Table SMT Dispenser,SMT Solder Paste Dispenser |
||
Dual Table Desktop SMT Dispenser Solder Paste Dispenser 200x300mm
SMT Dispenser Application Scope:
Thermal conductive adhesive, SMT bottom filling, component packaging, solder paste, red adhesive, UV adhesive, black adhesive, semiconductor packaging, wafer fixation, etc
SMT Dispenser Features:
1. Adopting computer control, Windows operating system, fault sound and light alarm, and menu display
2. CCD visual positioning system
3. Adopting servo motor+screw drive
4. Capable of carrying: pneumatic injection valve, piezoelectric valve, screw valve, AB rubber valve, etc
5. The automatic constant temperature system of the valve body ensures consistent flowability of the coating
6. Optional laser height detection system, which can automatically calibrate the Z-axis height after workpiece deformation
7. Optional workpiece heating system to enhance the fluidity of the coating during bottom filling
8. Optional precision weighing system, intelligent control and detection of dispensing amount, ensuring consistency of dispensing
9 .Desktop type, can be placed on the production line.
10. DIY mode, free matches of axis and heads, head number range is 1~12.
11. Multi-axis design with high rigidity aluminum alloy.
12. Double Y axis type, automatic working alternatively, saving the time of placing object.
13. The glue automatic feeding, safe and silence.
14. Main components of the machine are high quality, ensure the reliability and accuracy.
SMT Dispenser Specification:
| Model | SMTDR6 |
|
Working area X/Y/Z(mm) |
200*400, Dual Tables |
|
Max load Y-axis/Z-axis |
10kg/5kg |
|
Moving speed X&Y/Z(mm/sec) |
0.1-800/500 |
| Relolution | 0.01mm/Axis |
| Repeatability | ±0.01mm/Axis |
| Program capacity | No Limit |
| Data storage type | PC Windows 10 |
| Coating Capacity | 30CC |
| Display | LCD |
| Number of axis | 4 |
| Programming method | Visual programming |
| Valve nozzle cleaning device | Optional |
| Power | AC110V/220V |
| Working tem. | 5-50℃ |
| Power Rate | 2.5KW |
| Air pressure | ≥ 0.65Mpa |
| valve quantity | 1(standard) |
| Working Humidity | 20-90% no condensation |
|
Dimension (W*D*H)mm |
950*850*850 |
| Weight(Kg) | 150 |
