Product Details:
|
| Warranty: | 1 Year | Control: | PC |
|---|---|---|---|
| Belt Width: | 350mm | Moving Speed: | 800mm/s |
| Program Mode: | Visual CCD System | Repeatable Precision: | ±0.02mm |
| On-site Training: | Provided | Name: | SMT Dispenser |
| High Light: | Online Smt Glue Dispenser Machine,Windows 10 OS Smt Glue Dispenser,800mm/s Glue Dispenser |
||
±0.02mm Windows 10 OS Online Glue Dispensing System SMT Dispenser
SMT Dispenser Function:
1. It is used in dispensing applications of glues, oils, greases, epoxy, silicones, sealants, cyanoacrylates, solder pastes, and other assembly fluids. 2. It can also be used for conformal coating. Conformal Coating is a thin polymeric film that is applied onto Printed Circuit Boards (PCBs) to protect the board's components/electronic circuitry to protect against moisture, dust, chemicals, and temperature extremes.
SMT Dispenser Features:
1. PC control, Windows 10 operation system.
2. CCD visual position system.
3. Servo motor+ ball screw drive.
4. Automatic nozzle constant temp. system , which ensure the consistence of the glue flow.
5. Automatic clean system.
6. SMEMA interface.
7. Different types of nozzle are optional.
SMT Dispenser Specification:
| Model | SMTID2X |
| Working Stroke | 410x350x100mm |
| Moving Speed | 800 mm/sec |
| Conveyor Belt Speed | 200 mm/sec |
| Driven Mode | (Stepping + belt) or (servo + screw rod) |
| Program Mode | Visual CCD System |
| Repeatable Precision | ±0.02mm |
| OS | Windows 10 |
| Valve Quantity | 1 |
| Warranty | 1 year |
| Glue Packaging | Up to client's requirement |
| Transport height | 900±20mm |
| Transport direction | L→R(R→L Optional) |
| Driven Type | Pneumatic |
| Precision | High |
| Certification | CE |
| Condition | New |
| Nozzle | Optional |
| Air Pressure | 0.7MPa |
| Power | 220V, 1100W |
| Dimension (W*D*H) | 1400x750x1730mm |
| Weight | 280kgs |
SMT Dispenser Technical Parameters:
Outer dimension L/W/H : 1400*750*1730(mm)
Workspaces: X 410mm Y350mm Z100mm
Maximum movement speed: 500mm/s
Input speed: 0-200mm/s
Loading weight: Z 8KG Conveyor belt 30KG
Weitht: 300KG
Control of operation: Motion card
Program: PC
Belt driven: Closed-loop stepper motor
Repetitive accuracy ± 0.02mm
Recognition accuracy 0.15mm
Input voltage AC220/50-60HZ
Working pressure 0.7Mpa
Equipment power 1100W
