PLC Control Automatic Solder Paste Dispenser Machine Epoxy Glue Dispenser

PLC Control Automatic Solder Paste Dispenser Machine Epoxy Glue Dispenser
PLC Control Automatic Solder Paste Dispenser Machine Epoxy Glue Dispenser

Large Image :  PLC Control Automatic Solder Paste Dispenser Machine Epoxy Glue Dispenser

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTDR311
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD10000/Unit
Packaging Details: Plywood case
Delivery Time: 30 days
Payment Terms: T/T, Western Union
Supply Ability: 100 Units/Month

PLC Control Automatic Solder Paste Dispenser Machine Epoxy Glue Dispenser

Description
Condition: 100% New Testing Report: Provided
Working Stroke: 400*400mm/300*300mm Filling Station: Optional
Program Mode: Teaching Box Repeatable Precision: ±0.05mm
Axis: 3 Name: Automatic Solder Paste Dispenser
High Light:

Automatic Solder Paste Dispenser Machine

,

PLC Solder Paste Dispenser Machine

,

Smt Epoxy Glue Dispenser

PLC Control Automatic Solder Paste Dispenser Machine Epoxy Glue Dispenser





Automatic Solder Paste Dispenser Advantages:

1. Teach pendant for easier programming

2. Supporting array,graphic browsing,3D arc,common graphic library inserting and group editing

3. Mini SD file memorizer high speed and 2G capacity

4. Automatic gel prevention to prevent glue curing to jam nozzle.



Available Dispensing Materials:

UV glue, AB glue, EPOXY (black glue), white glue, EMI conductive glue, SILICON, epoxy resin, instant glue, silver glue, red glue, solder paste, thermal grease, solder paste, transparent paint, screw glue, etc.



Automatic Solder Paste Dispenser Application:

1. Electrical Products: Electronic parts, integrated circuits, circuit board solder paste, fixed and dust and moisture protection, LCD liquid crystal screen, speakers, headphone, audio, LED, optical lens, SMD transformers, relays.

2. Communication Products: Keypad, mobile phone casing bonding, radio, telephone, Computers, MP4, electronic toys, chassis bonding, switches, connectors, plug cable.



Automatic Solder Paste Dispenser Characteristic:

◆ Major functions: Drawing point, line, surface, arc, circle, irregular curve continuous complement and triaxial linkage.
◆ Equipped with pro. software that has area display, translation rotating operation functions.
◆ Be able to set size of gluing area, speed of gluing, dispensing time, stopping glue time. Stable glue exudation without glue leaking and dripping.
◆ According to the production process, work platform can be installed with positioning PIN, glue guns, baseboard heating temperature controlling device.
◆ High-strength equipment frame, x, y, z axis vertical more precision

◆Stand-alone operation, most easy to install



Automatic Solder Paste Dispenser Specification:

Model SMTDR311
Working Area 300(X)x300(Y)x100(Z)mm
Moving Speed 0-500mm/second
Max load Y/Z 10/5KGS
XYZ Repeatability ±0.02mm
Machine Dimension 600x530x800mm
Driven Mode Stepping motor+ belt+ precise linear guide rail
Program capacity 999 parameter files(65535 points can be saved per file)
Operation system LCD panel /handhold programming device
Movement pattern Point to point in XYZ axis, Continuous line, arc
I/O ports for extension 4 inputs/4 outputs
Work condition Temperature 0-40°C;humidity 20-95%
Weight 46kgs
Power consumption 1KW/H


Optional Valves For Different Applications:
PLC Control Automatic Solder Paste Dispenser Machine Epoxy Glue Dispenser 0
PLC Control Automatic Solder Paste Dispenser Machine Epoxy Glue Dispenser 1
PLC Control Automatic Solder Paste Dispenser Machine Epoxy Glue Dispenser 2

After-Sales Service:
1. From the purchase date, one year free warranty, lifelong maintenance.
2. Provide technical update and technical service at any time.
3. Software system life - long free upgrade, to ensure the latest version of the software and perfect functions.
4. Provide technical training according to customer needs.
5. Make phone calls and on-site visits to customers from time to time, communicate with customers and improve related problems in a timely manner.
6. Provide door-to-door service, one-on-one designated service policy.
7. We are online for 24-hours, and give response to clients within 4 hours.
