Product Details:
|
| Warranty: | 1 Year | Driven: | Pneumatic |
|---|---|---|---|
| Working Stroke: | 400*350mm | Moving Speed: | 800mm/s |
| Program Mode: | Visual CCD System | Repeatable Precision: | ±0.02mm |
| On-site Training: | Provided | Name: | Automatic Glue Dispensing System |
| High Light: | Conveyor Belt Smt Glue Dispenser,200mm/sec Conveyor Belt Glue Dispenser,High Speed Smt Glue Dispenser |
||
High Speed Conveyor Belt SMT Automatic Glue Dispensing System
Automatic Glue Dispsensing System Description:
Dispensing Equipment are used in dispensing applications of glues, oils, greases, epoxy, silicones, sealants, cyanoacrylates, solder pastes, and other assembly fluids. Dispensing Machines can also be used for conformal coating. Conformal Coating is a thin polymeric film that is applied onto Printed Circuit Boards (PCBs) to protect the board's components/electronic circuitry to protect against moisture, dust, chemicals, and temperature extremes. SMT Devices carries new and used SMT dispenser machines, has conformal coating machines for sale, fluid dispensing, precision fluid dispensers, systems, precision fluid dispensers, and SMT glue dispenser machine, SMT adhesive dispenser, SMT solder paste dispenser.
Automatic Glue Dispsensing System Features:
1. The machine adopts visual positioning and following technology, without fixture, and the assembly line does not stop working.
2. The working mode of on-line dispensing combines product dispensing and handling procedures, and can be adapted to a variety of production lines
3. The layout mode of the new embedded model can be placed and used with the solid line, and the layout is flexible to meet the needs of flexible production.
4. It can be adapted to various dispensing valves and glue supply systems, which is simple to operate, easy to learn and easy to use.
5. SMEMA communication.
6. ESD flat belt transmission for high volume production.
7. The embedded display makes the machine smaller and more compact.
Automatic Glue Dispsensing System Specification:
| Model | SMTID2X |
| Working Stroke | 410x350x100mm |
| Moving Speed | 800 mm/sec |
| Conveyor Belt Speed | 200 mm/sec |
| Driven Mode | (Stepping + belt) or (servo + screw rod) |
| Program Mode | Visual CCD System |
| Repeatable Precision | ±0.02mm |
| OS | Windows 10 |
| Valve Quantity | 1 |
| Warranty | 1 year |
| Glue Packaging | Up to client's requirement |
| Transport height | 900±20mm |
| Transport direction | L→R(R→L Optional) |
| Driven Type | Pneumatic |
| Precision | High |
| Certification | CE |
| Condition | New |
| Nozzle | Optional |
| Air Pressure | 0.7MPa |
| Power | 220V, 1100W |
| Dimension (W*D*H) | 1400x750x1730mm |
| Weight | 280kgs |
