Dual Table Semi Automatic Laser PCB Depaneling Machine Without Stress

Dual Table Semi Automatic Laser PCB Depaneling Machine Without Stress
Dual Table Semi Automatic Laser PCB Depaneling Machine Without Stress
Dual Table Semi Automatic Laser PCB Depaneling Machine Without Stress Dual Table Semi Automatic Laser PCB Depaneling Machine Without Stress

Large Image :  Dual Table Semi Automatic Laser PCB Depaneling Machine Without Stress

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTL350
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-150K/set
Packaging Details: Plywood case
Delivery Time: 5-30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets per month

Dual Table Semi Automatic Laser PCB Depaneling Machine Without Stress

Description
PCB Type: V-cut And Tab Boards Laser: According To Clients' Requirement
PCB Material: FR4, FPC Fixture: Customized
Tables: 2 Name: PCB Laser Cutting Machine
High Light:

Semi Automatic Laser PCB Depaneling Machine

,

Dual Table Laser Depaneling Machine

,

FR4 PCB Laser Cutting Machine

Dual Table Semi Automatic Laser PCB Depaneling Machine Without Stress



Dual Table Semi-automatic PCB Laser Cutting Machine Without Stress



PCB Laser Cutting Machine Applications:

5G materials cutting, such as CCM / COB / LCP / MPI / COF / cop / pi / CPI in consumer electronics.

FPC cutting.

FR4 PCB cutting.

Glass cutting.



PCB Laser Cutting Machine Introduction:

The gantry structure and flying light path design make it easy to connect to the production line. It can be equipped with a special

loading and unloading IN-LINE system according to production needs to realize automatic production and greatly improve production efficiency.It is a device tailored for FPC and PCB processing. The working mode of the ordinary cutting machine can realize assembly line operation and double-station production,the smart model design,the closed optical path system can process products within450,which can be separated into a double platform 200 range,it is tailor-made for FPC and PCB processing.



PCB Laser Cutting Machine Characteristics:

1. High performance UV / green laser is adopted, with small laser focusing spot and narrow notch.

2. The board cutting process shall be clean and free of dust to avoid circuit failure caused by conduction caused by waste.

3. The PCB board that has been pasted can be divided directly. There is no contact and stress during cutting.

4. High precision two axis working platform, high precision and fast speed.

5. CCD can be used for automatic positioning and correction.

6. The processing is automatically controlled by computer software, and the software interface gives real-time feedback to understand the processing status in real time.



PCB Laser Cutting Machine Specification:

Laser Type UV, picosecond
Laser Wavelength 355nm
Laser Source 10/15/20W
Positioning Precision ±3μm
Repeation Precision ±2μm
Working Area 350*400mm(Dual Table)
Scanning Speed 2500mm/s
Working Field 40*40mm
Cooling Mode Water cooling
Water Cooler Yes
Exhaust Yes
Positioning Method Customized fixture(FR4)
Warranty 1 year
Testing Report Provided
Package Wooden case



PCB Laser Cutting Machine Advantages:

1. No dust

2. High cutting precision

3. No stress

4. For special-shaped cutting, it is easy to automate

5. High compatibility

6. Good cutting edge effect
