Dual Table Automatic PCB Cutting Machine PCB Depaneling Router Equipment

Brand Name:	Winsmart
Model Number:	SMTR05
MOQ:	1 Set
Price:	USD20000-80000
Packaging Details:	Plywood case
Payment Terms:	T/T, L/C, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

PCB Type:

Tab PCB

Spindle Speed:

60000rpm

Cutting Precision:

±0.05mm

Feature:

Top Cutting

Cutting Speed:

1-100mm/s

Condition:

Cleaning System:

Product Name:

Automatic PCB Cutting Machine

Supply Ability:

100 Sets/Month

Highlight:

Dual Table Automatic PCB Cutting Machine

60000rpm PCB Cutting Machine

Automatic PCB Depaneling Router Equipment

Product Description

Dua Table Automatic PCB Cutting Machine PCB Depaneling Router Equipment

Automatic PCB Cutting Machine Overview:

It is a machine for depaneling irregular PCB boards connected by milling bridge, it can cut straight lines, arc, circle according to the programs.

This depaneling way has low cutting stress to improve product quality.

Automatic PCB Cutting Machine Features:

1. Dual tables, milling cutter keep working all the time, suitable for high volume production, wihout interruption by loading and unloading.

2. High speed spindle is used for precise depaneling, to improve productivity and ensure smooth cutting edge.

3. Optional top and bottom cleaning system is available, ensure dust free and noise free.

4. High quality hardware, ensure high rigidity and good performance.

5. Fast cutting speed, max 0.5 second per cutting point.

6. Custmized fixture ensure precise cutting for smooth cutting edge, no burr.

7. 1-year warranty, 24 hours online service.

Automatic PCB Cutting Machine Specifications:

Router Machine	SMTR05
X/Y Cutting Speed	0 ~100mm/s
Repeatability precision	± 0.01mm
X/Y1/Y2/Z control mode	Industrial IPC and PC
X/Y1/Y2/Z driven mode	AC Servo Motor
Operation and data storage	PC
Operation system	Win 10
Language	English
Cutting Precision	± 0.05mm
Camera	Germany brand
Positioning	Fixture
Spindle Speed	60000rpm(Germany KKAVO)
Automtic positioning	Yes
Power Supply	220V/110V
Air Pressure	4.5kg/cm 2
Power Rate	1.8KW
Vacuum Cleaner
Mode	Top or Bottom
Power Supply	380V
Top Cleaner Dimension	L650W400H1350mm
Bottom Cleaner Dimension	L665W635H1650mm

Automatic PCB Cutting Machine FAQ:

Q: What is warranty of this machine?

A: 1 year.

Q: What is the spindle used?

A: Germany Sycotec.

Q: What is routing bit life time?

A: About 100 meters per each.

Q: How does the PCB fix during cutting?

A: Customized fixture.

Q: How thick of PCB board can be cut?

A: Less than 2.5mm.
