Penumatic Economic LED PCB Punching Machine With LCD Display

Certification
China Winsmart Electronic Co.,Ltd certification
China Winsmart Electronic Co.,Ltd certification
Customer Reviews
The machine is on our production line being used and working well! It was a pleasure doing business with you!

—— Thomas

All your PCB depaneling machines are working very well, as we have been used them for more than 5 years! Qualified equipments! Excellent service!

—— Gary

I'm Online Chat Now

Penumatic Economic LED PCB Punching Machine With LCD Display

Penumatic Economic LED PCB Punching Machine With LCD Display
Penumatic Economic LED PCB Punching Machine With LCD Display Penumatic Economic LED PCB Punching Machine With LCD Display

Large Image :  Penumatic Economic LED PCB Punching Machine With LCD Display

Product Details:
Place of Origin: China
Brand Name: Winsamrt
Certification: CE
Model Number: SMTP300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/set
Packaging Details: Plywood case
Delivery Time: 7-15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets

Penumatic Economic LED PCB Punching Machine With LCD Display

Description
Air: 0.4-0.7MPa Working Area: 330x220mm
Output: Optional 3/8/10/15Ton PCB Thickness: 0.08-3.5mm
Driven: Air Name: LED Punching Machine
High Light:

Pneumatic LED PCB Punching Machine

,

LCD Display PCB Punching Machine

,

0.7MPa Pcb Depaneling Machine

Penumatic Economic LED PCB Punching Machine With LCD Display





LED Punching Machine Description:

PCB punching machine is using a customized die tooling with bites to cut milling joints, so that single PCBA are separated in a few seconds from the larger PCBA panel. This separation method is suitable for very high volume production.



LED Punching Machine Advantages:

1. Customized punching die is used, avoiding micro-cracks caused by manual.

2. It is easy to replace and change punching dies for new application.

3. Air cylinder driven, friendly and environmental.

4. Sensors are installed for safe operation to avoid accident.

5. High work efficiency, 8-12 seconds cycle cutting time for high volume.





LED Punching Machine Specification:

Working area 330*220mm
Working pressure 0.45-0.7Mpa
Cutting precision ±0.05mm
Cycle time 7-15 seconds
Output 3-20T
PCB/FPC thickness 0.08-3.5MM
PCB/FPC material FPC, FR1, FR4, CEM-1, CEM-3, MCPCB
Cutting mode Punching
Punch fixture Die tooling(mold)
Working Property

LCD display, Automatically records the number of

processed products, automatic punching

Transmission port International standard
Operation Language English
Stroke 50MM
Mold height 170MM
Power 380/220V
Fuse 3A
Machine dimension 820x740x1750mm
Machine weight 580kgs





LED Punching Machine FAQ:

Q: How to replace die tooling for new application?

A: It is easy and convenient, loosen screws to remove old die tooling, and put new die tooling on the machine then lock screws.

Q: What is your warranty?

A: 1 year for punching machine, 3 months for die tooling.

Q: What is life time of die tooling for the punching machine?

A: About 300,000-500,000 shots.

Q: What is PCB material available?

A: FR4, Alunium, FPC, etc.

Q: What is cycle punching time?

A: 7-12 seconds.



Contact Details
Winsmart Electronic Co.,Ltd

Contact Person: Ms. Amy

Tel: +86-752-6891906

Send your inquiry directly to us (0 / 3000)
