Straight Knife V Cut PCB Depaneling Machine For Max 600mm PCBA

Straight Knife V Cut PCB Depaneling Machine For Max 600mm PCBA
Straight Knife V Cut PCB Depaneling Machine For Max 600mm PCBA
Straight Knife V Cut PCB Depaneling Machine For Max 600mm PCBA Straight Knife V Cut PCB Depaneling Machine For Max 600mm PCBA

Large Image :  Straight Knife V Cut PCB Depaneling Machine For Max 600mm PCBA

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTPD2
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/set
Packaging Details: Plywood case
Delivery Time: 2-5 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month

Straight Knife V Cut PCB Depaneling Machine For Max 600mm PCBA

Description
Max Length: 600mm PCB Thickness: 0.4-5mm
Inspection Video: Provided PCB Material: FR1, FR4, MCPCB, CEM1, CEM3
Warranty: 1 Year Type: V Cut PCB Depaneling Machine
Highlight:

CEM3 V Cut PCB Depaneling Machine

,

Straight Knife PCB Depaneling Machine

,

Max 600mm PCBA V Cut Machine

Straight Knife V Cut PCB Depaneling Machine For Max 600mm PCBA





V Cut PCB Depaneling Machine Introduction:

In order to improve cutting effect from hand breaking, many manufacturer choose below V Cut PCB depaneling machine.

It is suitable for all rigid V-cut panels, and it has very low cutting stress to protect components well.



V Cut PCB Depaneling Machine Specification:

Model SMTPD2-400
Machine Dimension 720x300x440mm
Max Cutting Length 330mm
PCB Material FR4, MCPCB, CEM, Copper Boards
Air Pressure 0.4-0.7MPa
PCB Thickness 0.3-3.5mm
Condition New
Blade Material High speed steel
Customized Blade Available
Blade Re-sharpen Yes
Power 110/220V
Machine Weight 130kgs



V Cut PCB Depaneling Machine Features:

1. It uses 2 linear blades to separate without stress, especially suitable for cutting precision SMD boards.
2. ESD sheet could be added to platform to hold the separated PCBA.
3. The blade is made of imported high-speed steel, which is durable and it is re-sharpened 2-3 times.

4. It is suitable for FR1, FR4, CEM and aluminum PCB of various thickness.
