Water Cooling Spindle Mini PCB Router Machine 100mm/s
  • Name

Water Cooling Spindle Mini PCB Router Machine 100mm/s

Brand Name: Winsmart
Model Number: SMTDR300
MOQ: 1 Set
Price: USD20000-80000
Packaging Details: Plywood case
Payment Terms: T/T, L/C, Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE
Color:
White
PCB Material:
FR4, Aluminum
PCB Thickness:
0.8-3.0mm
Advantage:
Easy Programming
Cutting Precision:
±0.05mm
Working Area:
400x400mm
Routing Bit:
Dia 0.8-2.5mm
Cutting Speed:
100mm/s
Certificate:
CE
Product Name:
Mini PCB Router Machine
Supply Ability:
100 Sets/Month
Highlight:

100mm/s Mini PCB Router

,

Mini PCB Router Machine Water Cooling

,

CE Bench Type Mini Pcb Router

Product Description

Water Cooling Mode China Brand Spindle Mini PCB Router Machine





Mini PCB Router Overview:

The bench type mini PCB router machine is a device that uses milling cutter to run at high speed to separate tab PCB boards according to the pre edited path. It replaces the cutting defects of manual breaking, V-cut or punching, improves product quality and reduces scrap rate.



Mini PCB Router Features:

1. Bench-top single table PCB router with speeds up to 100mm/s and positioning speeds of 500mm/s.

2. Teaching box for programming, easy to program for new products.

3. Fixture cost is low, saving manufacturing cost.

4. This PCB router is cost-effective, working table dimension could be customized according to client's PCB boards.

5. Lower cutting stress for very smooth cutting edge.



Mini PCB Router Specification:

Model SMTDR300
PCB material FR4, Aluminum
Drive system motor servo / stepper motor
Spindle domestic / imported spindle
Cutting performance 500mm / s
Drive system repeatability ± 0.02mm
Cutting speed Max 100mm / S depends on PCB material and cutting quality
Resolution ±0.01mm
XYZ Stroke 400 x 400 x 100mm(standard)
PCB positioning special or standard fixture
Handling method manual mode
Thickness of circuit board 0.4mm-4mm
Spindle power 0.5 kW
Spindle speed 40,000 rpm
Machine size 650x550x500mm
Weight 75KG





Mini PCB Router FAQ:

1.A: What is life time of routing bit?

   Q:150-300 meters.

2.A: Can this model cut Aluminum PCB boards?

   Q: Yes, it can.

3.A: What is warranty?

   Q: 12 months

4.A:What is the spindle type?

   Q:China brand water cooling spindle.
