Product Details:
|
Fixing Mode: | Customized Fixture | Solder Wire: | 0.6-1.6mm |
---|---|---|---|
Jig Loading: | 5kgs | Condition: | Original New |
Usage: | PCB Soldering | Name: | Spot Soldering Machine |
Highlight: | PCB Automatic Soldering Machine,PCB Spot Soldering Machine,1.6mm PCB Automatic Soldering Machine |
Multi-axis Automatic Soldering Machine Spot Soldering Machine
Spot Soldering Machine Overview:
This soldering robot is a robot with solering wire feeding motion system.
Spot Soldering Machine Features:
1.High power heating controller ensures the tip temperature to reach 350°C within 30 seconds;
2.With the sleeve design, the soldering tip can be replaced quickly and easily.
3.Intelligent solder feeding mode, parameters can be set freely.
4.Automatic tip cleaning function by airflow cleaning, the residual dross on the tip can be blown off easily.
Spot Soldering Machine Specifications:
Model | SMTSR213 |
Dimension | 680*500*720mm |
Weight | 90Kg |
Control | PLC |
Programming | Teaching box |
Driving mode | Stepper motor |
Stroke | 250(X)x300(Y1)x300(Y2)x80(Z) |
Soldering head | 1 |
Repeatability | ±0.02mm(X/Y/Z) |
Temp. Range | 0-550℃ |
Solder Wire Spec | ¢0.3-1.6mm |
Number of axes | 4 |
Working pressure | 0.4~0.6Mpa(No water mist) |
Power | AC110V/220V 300W |
Display | LCD |
Spot Soldering Machine Advantages:
1. Soldering Robot provides the best solution for soldering job on lead-free, heat dissipating PCB, and high thermal capacity components.
2. It is suitable for all sorts of difficult soldering tasks and micro soldering process.
3. It effectively improves the soldering quality and consistency.
4. It saves 30% of the solder consumption comparing to manual soldering.
