Product Details:
|
| Certification: | CE | Application: | Solder Component Leads |
|---|---|---|---|
| New: | Yes | Fixture: | Customized Made |
| Working Stroke: | 250(X1)x250(X2)x300(Y1)x300(Y2)x80(Z)x360°(R1)x360°(R2) | Name: | Soldering Iron Robotic Tools |
| High Light: | 300W Automated Soldering Machines,AC110V Automated Soldering Machines,PLC Controlled Robotic Soldering Machine |
||
Soldering Iron Robotic Tools Automated Soldering Machines 1S/Point
Soldering Iron Robotic Tools Overview:
A Soldering Robot is a fully automated system that performs a designated task, set by a custom program, with the utmost precision and repeatability. Each joint may have its own soldering profile. It is a very fast solution.
Soldering Iron Robotic Tools Features:
1. Flexible and diverse soldering methods, with spot welding, drag welding (pull welding) and other functions, and also built-in screwing, dispensing and handling procedures.
2. The equipment can store 99 operating procedures.
3. The same machine can process 99 different products by soldering tin.The mechanical arm of the equipment is made of aluminium profiles by open-die casting. It is not deformed, rust-free and runs steadily.
4. Programming can copy point-to-point and block-to-block to shorten the programming time.
5. The equipment has the function of automatic cleaning, which stabilizes the quality of soldering tin processing and prolongs the service life of soldering iron tip to a certain extent.
6. Multi-axis linkage manipulators are all driven by precision stepper motor and advanced motion control algorithm, which can effectively improve the accuracy of motion positioning and repetition.
Soldering Iron Robotic Tools Specifications:
| Model | SMTSR224 |
| Dimension | 680*500*720mm |
| Weight | 90Kg |
| Control | PLC |
| Programming | Teaching box |
| Driving mode | Stepper motor |
| Stroke | 500(X)x300(Y1)x300(Y2)x80(Z)x360(R) |
| Soldering head | 2 |
| Repeatability | ±0.02mm(X/Y/Z) |
| Temp. Range | 0-550℃ |
| Solder Wire Spec | ￠0.3-1.6mm |
| Number of axes | Multi |
| Working pressure | 0.4~0.6Mpa(No water mist) |
| Power | AC110V/220V 300W |
| Display | LCD |
