Laser PCB Machine Optional Green UV Laser Source Laser PCB Cutting Equipment

Brand Name:	Winsmart
Model Number:	SMTL460
MOQ:	1 set
Price:	USD1-150K/set
Packaging Details:	Plywood case
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Application:

FPC, PCB, Silicone, Glass, Etc

Power Rate:

Scan Range:

40x40mm

Positioning Ways:

Fixture

Cutting Stress:

Name:

Laser PCB Machine

Supply Ability:

100 sets per month

Highlight:

355nm Laser PCB Machine

Optional Green UV Laser PCB Machine

3KW Laser PCB Cutting Equipment

Product Description

Laser PCB Machine Optional Green UV Laser Source Laser PCB Cutting Equipment

Features:

1. Lasers make clean, burr-free and precise cuts against the edge of circuits and other important components—improving overall design flexibility without damaging the substrate.

2. Easy for programming by importing dxf files.

3. Smooth cutting edge.

4. Noise free.

PCB Laser Cutting Machine Specification:

Laser	Q-Switched diode-pumped all solid-state UV laser
Laser Wavelength	355nm
Laser Source	Optowave UV 15W@30KHz
Positioning Precision of Worktable of Linear Motor	±2μm
Repetition Precision of Worktable of Linear Motor	±1μm
Effective Working Field	460mmx460mm(Customizable)
Scanning Speed	2500mm/s (max)
Working field	40mmх40mm
