Desktop Automatic Soldering Machine Dual Head Robot Soldering

Desktop Automatic Soldering Machine Dual Head Robot Soldering
Desktop Automatic Soldering Machine Dual Head Robot Soldering

Large Image :  Desktop Automatic Soldering Machine Dual Head Robot Soldering

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTSR113
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/Set
Packaging Details: Plywood case
Delivery Time: 5-8 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300 sets per month

Desktop Automatic Soldering Machine Dual Head Robot Soldering

Description
After-sale Service: Operation Video And Online Support Soldering Head: 1
Warranty: 12 Months Control: PLC
Working Stroke: 400(X)400(Y)x80(Z) Name: Automatic Soldering Machine
High Light:

Desktop Automatic Soldering Machine

,

Dual Head Automatic Soldering Machine

,

PLC Control Robotic Soldering Machine

Desktop Automatic Soldering Machine Dual Head Robot Soldering





Automatic Soldering Machine Advantages:

1. Soldering Robot provides the best solution for soldering job on lead-free, heat dissipating PCB, and high thermal capacity components.

2. It is suitable for all sorts of difficult soldering tasks and micro soldering process. It effectively improves the soldering quality and consistency. 3. Besides, it saves 30% of the solder consumption comparing to manual soldering.



Automatic Soldering Machine Features:

Firstly, perfect soldering process setting, with spot welding and welding function. Each instruction has independent preheating, tin length, preheating time, welding time, tinning time, lifting height and other solder parameters. Secondly, perfect soldering process setting, with spot welding and drag welding function. Each instruction has independent preheating, solder wire length, preheating time, soldering time, tinning time, lifting height and other solder parameters. Third, support PLT format files, realize direct importing for easier operation.The forth, the machine can be run offline or independently, and the welding parameters are saved in the SD card to facilitate parameter copying and saving between devices.

Fifth, 2G storage space, can store several soldering programs, each program supports 9999 soldering instructions. Sixth, there are two options for solder wire feeding, broken tin function, no broken tin function. Seventh, the display adopts 320x240 high-resolution color screen, English operation interface, easy to operate.



Automatic Soldering Machine Specifications:

Model SMTSR113
Dimension 880*700*830mm
Weight 80Kg
Control PLC
Programming Teaching box
Driving mode Stepper motor
Stroke 300(X)x300(Y)x80(Z)
Soldering head 2
Repeatability ±0.02mm(X/Y/Z)
Temp. Range 0-500℃
Solder Wire Spec ¢0.3-1.6mm
Number of axes 4
Working pressure 0.4~0.6Mpa(No water mist)
Power AC110V/220V 300W
Display LCD



Automatic Soldering Machine Application:

Suitable for automotive electronics, digital, electronic, electro-acoustic, LCD, circuit board and other production industries, connectors, networks, transformers, cable, FPC / COF soldering, computer motherboards, CABLE, speakers and motors high quality soldering.
