Product Details:
|
| Testing Report: | Provided | PCB Material: | FR1, FR4, CEM1, CEM3, MCPCB |
|---|---|---|---|
| PCB Thickness: | 0.4-5mm | Cutting Length: | No Limit |
| Blade Life Time: | 6-12 Months | Platform: | 2.4M(Standard) |
| Condition: | New | Name: | LED PCB Cutting Machine |
| High Light: | LED PCB Cutting Machine,3 Pairs Blade PCB Cutting Machine,110V PCB Separator Machine |
||
3 Pairs Circular Blade LED PCB Cutting Machine 110V PCB Separator Machine
LED PCB Cutting Machine Overview:
This LED PCB cutting machine is designed to minimize board stress and avoid component damage. Three pairs of precision beveled cutting blades ensure the board does not bend or deform. The guide can be adjusted vertically to suit different LED boards.
Depth between upper circular blades can be precisely adjusted to reduce stress on score line edge and blade wear.
LED PCB Cutting Machine Specification:
| Model | SMTD3 |
| Machine Dimension | 400x400x330mm |
| Platform Dimension | 2400x300x200mm |
| Max Cutting Length | No limit |
| PCB Thickness | 0.4-3.5mm |
| Blade Quantity | 3 Pairs |
| Blade Material | High Speed Steel |
| Inspection Video | Provided |
| Testing Report | Provided |
| Certification | CE |
| PCB Material | FR4, MCPCB, Copper Boards |
| Cutting Speed | 0-500mm/s |
| PCB Thickness | 0.6-3mm |
| Power | 220/110V |
| Machine Weight | 44kgs |
| Wooden Case Dimension | 116x67x58cm |
| Gross Weight | 76kgs |
LED PCB Cutting Machine Advantages:
1. Separates panels up to 0.1"
2. The longest panel: No limit, workable for 1500mm LED PCB boards
3. Minimum board thickness of 0.024"
4. Shears boards safely with parts as close as 0.02" to score line.
5. Only allow correct boards placement to avoid mistakes.
6. Blades could be customized made
7. Workable for both FR4 and Alumimun PCB boards
LED PCB Cutting Machine Case:
