Inline V Cut PCB Separator Pneumatic PCB Cutting Machine Without Cutting Stress

Description
CE Approval: Yes Warranty: 1 Year
Voltage: 220V/110V PCB Connection: V-cut
Max Panel: 1200mm(could Be Cusomized Made) Name: Inline V-cut PCB Separator Machine
High Light:

Pneumatic PCB Cutting Machine

,

Inline V Cut PCB Separator

,

CE V Cut PCB Separator

Inline V-cut PCB Separator Pneumatic PCB Cutting Machine Without Cutting Stress





Customer Current Status:

1. Manual breaking, slow efficiency and high labor intensity
2. The qualified rate of products depends on manual work, and the strength is uncontrollable.
3. The workshop is unmanned.
4. Manual breaking has large stress and high labor cost.



Inline V-cut PCB Separator Functions:

1. Realize automatic depaneling
2. Product qualification rate is controllable.
3. Reduce labor costs and add more R & D funds to enterprises.
4. The machine can realize rapid type change and modular type change quickly.
5. One person can operate this multiple devices.



Inline V-cut PCB Separator Struture:

1. The equipment frame is constructed by 40 * 40 thickened square welding.

2. The tool holder adopts seamless butt joint, which will not scratch the lamp beads and boards.

3. The end track is 1300mm long and 520mm wide,It is manually loaded into the buffer area.



Inline V-cut PCB Separator Specification

Machine Dimension Name Inline V-Cut PCB Separator
Dimension 1500*800*1500mm
Weight 400kgs
Color White
Usage Requirements Power Supply AC220V, 1800W
Air Supply 0.6MPa
Environment Clean and dry, avoid humidity or high temperature
Min distance between component and scoring line 1.5mm
PCB Panel Range 1200mm
Max component height Upper 35mm, bottom 20mm
Software PLC Local brand
Parameter setting Setting on touch screen
Storage Available for 50 programs
Touch screen Taiwan brand
Sensor Omron
Blade Spec Material Japan high steel
Angel 10-30 degree
Life time 3,000,000 times
Knife mold precision 0.1mm
Replace knife mold time 60 minutes





Inline V-cut PCB Separator Photos:

Inline V Cut PCB Separator Pneumatic PCB Cutting Machine Without Cutting Stress 0  Inline V Cut PCB Separator Pneumatic PCB Cutting Machine Without Cutting Stress 1

Inline V-cut PCB Separator Working Environment: environment environment

Workshop: Clean room
Temperature:-5℃ - 42 ℃
Humidity: 10% - 90%
Noise: 40dB - 80dB
Vibration velocity : 1mm/s - 5mm/s
Power Supply:220VAC,50Hz or 110VAC, 60Hz
Air Supply: 5KGF/cm2
