355nm FPC Laser Cutting Machine SMT Machine Manufacturers

355nm FPC Laser Cutting Machine SMT Machine Manufacturers
355nm FPC Laser Cutting Machine SMT Machine Manufacturers
355nm FPC Laser Cutting Machine SMT Machine Manufacturers 355nm FPC Laser Cutting Machine SMT Machine Manufacturers

Large Image :  355nm FPC Laser Cutting Machine SMT Machine Manufacturers

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTL460
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Plywood case
Delivery Time: 5-30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets per month

355nm FPC Laser Cutting Machine SMT Machine Manufacturers

Description
PCB Thickness: 0.1-3mm Laser: UV 10/12/15W
Warranty: 1 Year CE Report: Provided
On-site Service: Provided Name: SMT Machine Manufacturers
High Light:

FPC Laser Cutting Machine

,

355nm Laser Cutting Machine

,

UV laser SMT Machine

FPC Laser Cutting Machine SMT Machine Manufacturers FPC Machine





Machine Introduction:

With the upgrading of electronic products, the main direction is to develop towards intelligent electronics, and the demand for FPC flexible printed circuit board will also increase greatly, because FPC flexible printed circuit board is a printed circuit made of flexible insulating substrate, which has many advantages that hard printed circuit boards do not have


1. It can be bent, wound and folded freely, can be arranged arbitrarily according to the spatial layout requirements, and can move and expand freely in three-dimensional space, so as to achieve the integration of component assembly and wire connection.

2. FPC can greatly reduce the volume and weight of electronic products, which is suitable for the development of electronic products in the direction of high density, miniaturization and high reliability. Therefore, FPC has been widely used in aerospace, military, mobile communication, laptop, computer peripherals, PDA, digital camera and other fields or products.

3. FPC also has the advantages of good heat dissipation and weldability, easy assembly and low comprehensive cost. The design of soft and hard combination also makes up for the slight deficiency of flexible substrate in component bearing capacity to a certain extent.



In view of the current hot trend of FPC soft board application in electronic products, Fusen Flex PCB depaneling machine and FPC laser cutting machines have also achieved good sales performance, mainly due to the strong demand of the market and the quality and performance.



Machine Principle:

The principle of laser PCB cutting machine is to irradiate the surface of PCB circuit board with high-energy beam, and realize the vaporization cutting of PCB materials by controlling the parameters such as beam energy density, frequency, speed and processing times.



Machine Advantages:

More quick and easy, shorten the delivery time. High quality, no distortion, surface clean& uniformity. Smooth cutting edge, no cutting stress, no burrs.



Machine Specification:

Laser Q-Switched diode-pumped all solid-state UV laser
Laser Wavelength 355nm
Laser Source Optowave UV 15W@30KHz
Positioning Precision of Worktable of Linear Motor ±2μm
Repetition Precision of Worktable of Linear Motor ±1μm
Effective Working Field 460mmx460mm(Customizable)
Scanning Speed 2500mm/s (max)
Working field 40mmх40mm
