Product Details:
|
PCB Material: | FR4, Aluminum | Spindle: | Optional |
---|---|---|---|
Cutting Precision: | ±0.05mm | Feature: | Top Cutting |
Cutting Speed: | 1-100mm/s | Cleaner Weight: | 150kgs |
Vacuum Cleaner: | 3HP/2.2KW | Product Name: | CNC PCB Router Machine |
Highlight: | 60000rpm CNC PCB Router Machine,Tab Board CNC PCB Router Machine,AC Servo Motor PCB Depaneling Tool |
CNC PCB Router Machine Tab Board PCB Depaneling Tool From Top Cutting
CNC PCB Router Machine Description:
PCB router machine is a machine for depaneling irregular PCB boards connected by stamp holes. Also known as PCB router machine, desktop PCB router machine, stamp hole PCB depaneling router. PCB router machine is an important process in the PCB manufacturing process. PCB router refers to cutting the graphics required by the customer through the routing bits according to the processing program designed by the project.
CNC PCB Router Machine Features:
1. Bench type single bench cutting machine, with speed up to 100mm / s and positioning speed of 500mm / s.
2. Continuous cutting without interruption during loading and unloading.
3. The high-quality rotating shaft system enables the system to accelerate and decelerate quickly, reduce the synchronization time, improve productivity and maintain high precision.
4. High quality hardware is used to ensure high rigidity and high performance.
CNC PCB Router Machine Specifications:
Router Machine | SMTR05 |
X/Y Cutting Speed | 0 ~100mm/s |
Repeatability precision | ± 0.01mm |
X/Y1/Y2/Z control mode | Industrial IPC and PC |
X/Y1/Y2/Z driven mode | AC Servo Motor |
Operation and data storage | PC |
Cutting Precision | ± 0.05mm |
Spindle Speed | 60000rpm(Germany KKAVO) |
Power Supply | 220V/110V |
Air Pressure | 4.5kg/cm 2 |
Power Rate | 1.8KW |
Vacuum Cleaner | |
Mode | Up or Bottom |
Power Supply | 380V |
Up Cleaner Dimension | L650*W400*H1350mm |
Bottom Cleaner Dimension | L665*W635*H1650mm |
CNC PCB Router Machine Dual Working Tables:
Our Service:
1. Lifetime technical support and 2 years warranty.
2. Free replacement or refund would be done in case of any quality problem.
3. Fast response/feedback within 12 hours
4. Engineers are available to be sent to do oversea installation and training.
5. Solid packaging to prevent damage from transportation.
