Product Details:
|
| Mode: | PLC Control | Soldering Tip: | Customizable |
|---|---|---|---|
| Fixture: | Customizable | Power: | 220/110V |
| Working Stroke: | Customizable | Name: | Soldering Robot Welding Machine |
| High Light: | PCB Soldering Robot Welding Machine,110V 3 Axis Robot Welding Machine,PLC Robotic Soldering Machine |
||
2021 Automatic 3 Axis Soldering Robot Welding Machine For PCB Soldering
Soldering Robot Welding Machine Introduction:
Automatic soldering machine, as known as soldering robot, is mainly used for SMT soldering process of components that cannot pass the reflow soldering machine as the heat sensitivity.
Soldering Robot Welding Machine Features:
1. With automatic smoke collection to keep the air clean (optional).
2. High-strength solder head can be customized for high quality melding.
3. Program can be fast made by re-set ,insert and delete the spot of the soldering or full modification.
4. Clamping slot for easily fetch and change the products.
5. Feeding tins at anytime to apply for multiple welding and high efficiency.
6. Weller soldering temperature controller, control the temperature more accurately and more durable.
7. Auto anti-collapse.
8. Programming with teaching pendant for all new users to operate within 2 hours.
9. Auto transport tape is optional for full automatic.
10. The mode of two users managements of different right for engineer and operator.
11. With functions of calibration of R axis, correction of wrong operations.
12. ±0.02mm repeated precision to achieve precised soldering.
Soldering Robot Welding Machine Specifications:
| Model | SMTSR113 |
| Dimension | 880*700*830mm |
| Weight | 70Kg |
| Control | PLC |
| Programming | Teaching box |
| Driving mode | Stepper motor |
| Stroke | 300(X)x300(Y)x80(Z) |
| Soldering head | 1 |
| Repeatability | ±0.02mm(X/Y/Z) |
| Temp. Range | 0-500℃ |
| Solder Wire Spec | ￠0.3-1.6mm |
| Number of axes | 3 |
| Working pressure | 0.4~0.6Mpa(No water mist) |
| Power | AC110V/220V 300W |
| Display | LCD |
Soldering Robot Welding Machine Application:
