Desktop Robotic PCB Iron Soldering Machine With Multi Axis

Desktop Robotic PCB Iron Soldering Machine With Multi Axis
Desktop Robotic PCB Iron Soldering Machine With Multi Axis
Desktop Robotic PCB Iron Soldering Machine With Multi Axis Desktop Robotic PCB Iron Soldering Machine With Multi Axis

Large Image :  Desktop Robotic PCB Iron Soldering Machine With Multi Axis

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTSR123
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Plywood case
Delivery Time: 5-8 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300 sets per month

Desktop Robotic PCB Iron Soldering Machine With Multi Axis

Description
Warranty: 12 Months Soldering Tip: 2
Fixture: Customized Power: 220/110V
Working Stroke: Customizable Name: PCB Iron Soldering Machine
High Light:

Robotic PCB Iron Soldering Machine

,

Multi Axis Iron Soldering Machine

,

Desktop PCB Iron Soldering Machine

Automatic Multi Axis Desktop Robotic PCB Iron Soldering Machine





PCB Iron Soldering Machine Features:

・ Suitable for different products, welding temperature can be set freely (each welding point can be set different temperature)
・ Welding components can be adjusted and buffered in various directions to ensure that the welding original and PCB are not damaged.
・ Temperature control (still air state ± 1C)
・ A digital pressure gauge is provided to prevent the pressure from exceeding the pressure range.
・ During the use of the welding head, the heating and cooling are fast, the heat transfer coefficient is good, and the wear
resistance is good.



PCB Iron Soldering Machine Parameters:

Model SMTSR123
Dimension 680*500*720mm
Weight 80Kg
Control PLC
Programming Teaching box
Driving mode Stepper motor
Stroke 400(X)x300(Y1)x300(Y2)x80(Z)
Soldering head 2
Repeatability ±0.02mm(X/Y/Z)
Temp. Range 0-550℃
Solder Wire Spec ¢0.3-1.6mm
Number of axes 4
Working pressure 0.4~0.6Mpa(No water mist)
Power AC110V/220V 300W
Display LCD



PCB Iron Soldering Machine Application:

Desktop Robotic PCB Iron Soldering Machine With Multi Axis 0
