Automatic PCB Punching Machine For Printed Circuit Board
  • Name

Automatic PCB Punching Machine For Printed Circuit Board

Brand Name: Winsamrt
Model Number: SMTP300
MOQ: 1 set
Packaging Details: Plywood case
Payment Terms: L/C, T/T, Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE
Color:
White
Certificate:
CE Approval
Output:
8/10/15T/20T
PCB Thickness:
0.08-3.5mm
Punching Fixture:
Die Tooling
PCB Material:
CEM, FR4, MCPCB
Warranty:
1 Year For Machine
Name:
Automatic PCB Punching Machine
Supply Ability:
100 sets
Highlight:

Automatic PCB Punching Machine

,

Printed Circuit Board PCB Punching Machine

,

CEM PCB Punching Machine

Product Description

Automatic PCB Punching Machine For Print Circuit Board FPC Punch





Automatic PCB Punching Machine Features:

1. High Efficiency. FPCs can be divided into 6 to 8 pieces in one minute.

2. The surface of the product is flat and uniform.

3. Low noise, no dust, thus reducing environment pollution.

4. Low Energy, the main power of consumption is compressed air.

5. Using our PCB punching machine help to low labor intensity for employee.

6. Adopt the lower die automatic entry and exit slitting method, which is protected by both grating and safety door. The operator is very safe to operate it.



Automatic PCB Punching Machine Specification:

Working area 400*300mm　
Working pressure 0.45-0.7Mpa
Cutting precision ±0.05mm
Cycle time 7-15 seconds
Output 8T
PCB/FPC thickness 0.08-3.5MM
PCB/FPC material FPC, FR1, FR4, CEM-1, CEM-3, MCPCB
Cutting mode Punching
Punch fixture Die tooling(mold)
Working Property

LCD display, Automatically records the number of

processed products, automatic punching
Transmission port International standard
Operation Language English
Stroke 50MM
Mold height 170MM
Power 380/220V
Fuse 3A
Machine dimension 820x740x1750mm
Machine weight 580kgs





Automatic PCB Punching Machine Details:

Automatic PCB Punching Machine For Printed Circuit Board 0

Automatic PCB Punching Machine For Printed Circuit Board 1



Tags:

Flex boards PCB Punching Machine

25T PCB Punching Machine

25T PCB die cutting machine
