10 Ton Die Tooling PCB Punching Machine Air Driven 500 Watt

Brand Name:	Winsamrt
Model Number:	SMTP300
MOQ:	1 set
Packaging Details:	Plywood case
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Power(w):

500 Watt

Power Source:

Air Driven

Application:

FR4 Substrate Cutting,aluminum Substrate,FPC/PET/PVC.etc.

Condition:

Warranty:

12 Months

Description:

Die Tooling PCB Punching Machine

Supply Ability:

100 sets

Highlight:

Die Tooling PCB Punching Machine

Air Driven PCB Punching Machine

500 Watt PCB Punching Machine

Product Description

10Ton Customized Punching Mold Die Tooling PCB Punching Machine

Die Tooling PCB Punching Machine Introduction:

1. Double switch start operation.

2. Device configuration mode and out of the chute,and out of the lower mold automatic pick and place convenient and safe products.

3. Emergency stop switch,identify problems and timely shutdown.

4. Security doors,installation and commissioning of the mold to avoid straying hands.(Normal operation with out security door doesnot work).

5. Safety pressure setting function,limit alarm.Automatic counting,limit down time.

6. The internal stress generated when the cutting board to a minimum and to avoid cracking of tin.

7. Suitable for high volume routed boards.

Die Tooling PCB Punching Machine Advantages:

1. Pneumatic, environmental protection

2. High efficiency, suitable for high volume PCBs

3. Security door protection, ensure safe production

Die Tooling PCB Punching Machine Specification:

Working area	460*320mm
Working pressure	0.45-0.7Mpa
Cutting precision	±0.05mm
Cycle time	7-15 seconds
Output	10T
PCB/FPC thickness	0.08-3.5MM
PCB/FPC material	FPC, FR1, FR4, CEM-1, CEM-3, MCPCB
Cutting mode	Punching
Punch fixture	Die tooling(mold)
Working Property	LCD display, Automatically records the number of processed products, automatic punching
Transmission port	International standard
Operation Language	English
Stroke	50MM
Mold height	170MM
Power	380/220V
Fuse	3A
Machine dimension	820x740x1750mm
Machine weight	680kgs

Suitable Application:
