LED Board Multi Blades Aluminum PCB Separator Machine PLC Control

LED Board Multi Blades Aluminum PCB Separator Machine PLC Control
LED Board Multi Blades Aluminum PCB Separator Machine PLC Control

Large Image :  LED Board Multi Blades Aluminum PCB Separator Machine PLC Control

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTAD10
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Plywood case
Delivery Time: 2-5 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month

LED Board Multi Blades Aluminum PCB Separator Machine PLC Control

Description
PCB Thickness: 0.8-1.2mm CE Approval: Yes
Voltage: 220V/110V Warranty: 1 Year
Full Automatic: No Name: PCB Separator
Highlight:

Aluminum PCB Separator Machine

,

Multi Blades PCB Separator Machine

,

LED Board PCB Separator Machine

Specialized LED Board Multi Group Blades Aluminum PCB Cutting Machine Separator





Multi Group Blades Aluminum PCB Separator Introduction:

The machine is equipped with standard upper and bottom 20 groups of blades which can separate the 10 lines or more LED light bars at same time.all blades are made of endurable SKD11 high speed steel.


PCB clamping and conveying system ensure precise separating without deformation and burrs.

The machine adopts touch screen and PLC control system which can monitor production information,easy to operate.

Full english operation interface , easy to operate.



Multi Group Blades Aluminum PCB Separator Features:

1. It can cut many boards with multiple sets of knives work at the same time.

2. The knife flywheel is adjustable as a whole from 0 to 5mm

3. The distance between knives is regulable as well, satisfy to cutting the single PCB width from 15mm-20mm

4. The blade is made of Japan imported high speed and high precision steel material, which is durable and have a long service life.

5. It is convenient to adjust the cutting speed through rotary knob

6. No limits of the cutting length.

7. Thickness range of PCB: 0.8-3.5mm

8. With a conveyor belt line, the separated PCB can be send out directly to reduce pick- and-place.

9. The machine adopts multiple blade to separate boards with simple operation and high efficiency.



Multi Group Blades Aluminum PCB Separator Specification:

Max cutting length No limit
Min cutting length 100mm
Max panel width 220mm
Custom cutting width 300mm
Min PCB width 8mm
PCB thickness 0.8-3.5mm
Feeding speed 0-500mm/s
Working tem. 10-35℃
Blade material(auto-lock function) Imported high precision steel
Storge tem. -20-50℃
Voltage 110-220V
Dimension 2160*570*1050mm
