Product Details:
|
| Certificate: | CE | Original: | 100% New |
|---|---|---|---|
| Service: | On-site Installation And Training | Min Panel: | 122x12mm |
| Max Panel: | 300x300mm | Name: | V-cut PCB Separator |
| High Light: | Inline V-Cut PCB Separator Machine,PLC Control PCB Separator Machine,Multi Blade Pcb Cutter Machine |
||
Inline V-cut PCB Separator Machine With Multi-blade Sets PLC Control
Inline PCB Separator Functions:
1. This machine is used for PCB board depaneling after inserter.
2. It has the functions of automatic feeding and automatic loading, and the machine is easy to operate.
3. The setting of each parameter ensures the consistency of the board feeding and the board depaneling.
4. Precision stepper motor and SMC pneumatic components are used, with high repeatability.
5. Using Mitsubishi PLC and Taiwan touch screen, the operation interface is simple.
6. Efficiency: 15s / PC (150x150mm, 8 blade sets).
7. Safety sensors in working area.
Inline PCB Separator Features:
1. A single group of multiple cutters can be divided automatically, and different cutters can be made according to different products.
2. Equipped with acrylic cover to ensure safety.
3. The electrical control part can be selected in the man-machine interface, convenient to open or shield.
4. There is a dust collecting tray under the knife mold.
5. Adopt square welding frame, sheet metal sealing plate, steel paint baking on the surface.
6. Suitable for all V-groove panels.
7. Depaneling material: FR, aluminum
Inline PCB Separator Specification:
| Machine Dimension | Name | Inline V-Cut PCB Separator |
| Dimension | 1500*800*1500mm | |
| Weight | 600kgs | |
| Color | White | |
| Usage Requirements | Power Supply | AC220V, 1800W |
| Air Supply | 0.6MPa | |
| Environment | Clean and dry, avoid humidity or high temperature | |
| Min distance between component and scoring line | 1.5mm | |
| PCB Panel Range | 12x12mm – 300x300mm | |
| Feeding door adjustment | Fixed front side, adjutable back side | |
| Max component height | Upper 35mm, bottom 20mm | |
| Software | PLC | Local brand |
| Parameter setting | Setting on touch screen | |
| Storage | Available for 50 programs | |
| Touch screen | Taiwan brand | |
| Sensor | Omron | |
| Blade Spec | Material | Japan high steel |
| Angel | 10-30 degree | |
| Life time | 3,000,000 times | |
| Knife mold precision | 0.1mm | |
| Replace knife mold time | 60 minutes | |
| Other Function | Wrong operation protection | Sensor, software |
| Safe protection | Emergency stop switch | |
| Power and gas cut off function | Yes | |
| Self check function | Start up time monitoring, capacity monitoring, equipment fault information and automatic exclusion system |
Inline PCB Separator Photo:
