Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm

Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm
Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm

Large Image :  Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: PM0409
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: USD1-100/Set
Packaging Details: Plywood case
Delivery Time: 7-14 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 sets per month

Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm

Description
Material: PP + Metal Base Size: 355x320x563mm
Max Temp.: 80°C /120°C / 200°C ESD: Yes
Base: Plastic Or Metal Pitch: 10mm
Packaging: Carton + Wooden Plate Name: SMT PCB Magazine Rack
High Light:

ESD Anti Static PCB Magazine Rack

,

Durable Folding PCB Magazine Rack

,

355x320x563mm Smt Magazine Rack

Durable Folding SMT Loader ESD antistatic PCB magazine rack Size 355x320x563mm





SMT PCB Magazine Rack Features:

1. Simple structure in linear type ,easy in installation and maintation.
2. Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3. High pressure double crank to control the die opening and closing.
4. Running in a high automatization and intellectualization,no pollution
5. Apply a linker to connect with the air conveyor ,which can directly inline with filling machine



SMT PCB Magazine Rack Specification:

Name ESD PCB Magazine Rack
Surface resistance 104~106 Ω
Overall size 355x320x563mm
Storage capacity 50pcs
PCB Spec L355xW(50-250)mm
Side guide slot depth 3.5mm, width 5mm, pitch 10mm
Heat resistant 80°C/120°C/200 °C
Ref. Position A=34mm, B=34mm
Materials Aluminum + steel







SMT PCB Magazine Rack Details:

Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm 0

ESD PCB Magazine Rack Details:

1. Large storage capacity, can store 50pcs PCB boards, saving cost.

    Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm 1



2. Easy to install: made of side plates, top and bottom plates, levers, clips and screws, easy and convenient to assemble and disassemble.

Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm 2

3. ESD Plastic Clip: special design, easy to adjust and better for management.

Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm 3



4. ESD side plates: slot distance is adjustable according to PCB boards freely.

Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm 4



ESD PCB Magazine Rack Installation:

Durable Folding SMT ESD Antistatic PCB Magazine Rack Size 355x320x563mm 5

Our Service:

1. Guarantee for 12 months for all equipments.

2. Maintenance for whole life.

3. We will provide the consumable parts at an resonable price.

4. 24 hours x 7days online service, free technical support.

5. Machine has been tested before delivery.

6. We have manual instruction and Guiding Videos for installation, operation and machine's using and maintenance.

7. Oversea on-site installation and trainning is available.

8. Vacuum & wooden case packaging is provided free of charge for sea shipment.
