6 Axis Automatic Screw Locking Machine Air Blowing AC220V

6 Axis Automatic Screw Locking Machine Air Blowing AC220V
6 Axis Automatic Screw Locking Machine Air Blowing AC220V

Large Image :  6 Axis Automatic Screw Locking Machine Air Blowing AC220V

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTSD221
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/Set
Packaging Details: Plywood case
Delivery Time: 5-8 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month

6 Axis Automatic Screw Locking Machine Air Blowing AC220V

Axis: 6 Screw Shape: All
Power: 110V/220V Type: Suction
Service: 7x24H Online Service Name: Automatic Screw Locking Machine
High Light:

AC220V Automatic Screw Locking Machine


6 Axis Automatic Screw Locking Machine


M5.0 Automatic Screw Feeder System

6-axis Automatic Screw Locking Machine with Automatic Screw Feeding Presenter


Machine Overview:

This automatic screw locking machine is used for locking screws applied in electronics, household appliances, Auto, toy industry and so on, which can greatly improve the production efficiency.


Automatic Screw Locking Machine Features:

1. Wide universality, small in size, can cooperate with production line, convenient for product replacement.

2. High efficiency, the number of electric screwdriver of the Z axis is customizable according to customer’s requirements. Several electric screwdrivers can work at the same time, which is the work of a number of workers. For example, a desktop automatic screw locking machine with 4 electric screwdrivers can lock continually with 4 screws at one time; it can lock several products at the same time.

3. The Y axis can be made into double-station (that is, double Y axis),so the operator can load alternately.

4. Reduce the labor intensity of workers.

5. High degree of automation, easy operation which the staff can master and debug quickly. A worker can manage several machines at the same time.

6. Accurate torsion, convenient adjustment, and the quality of lock is guaranteed.

7. With the function of leak detection, once a screw did not fill in place it can fill continually or start alarm processing, which will reduce leak screws of the products and increase the qualified rate.



Automatic Screw Locking Machine Specifications:

Model SMTSD221
Moving range 250X*300Y*100Zmm
Processing range 230X*300Y*110Zmm
Repetitive accuracy ±0.02mm(X/Y/Z)
Fixture platform 2
Screw head 2
Applicable screw M1.0-M5.0
Screw conveying method Air blowing
Driving mode precision stepping motor+precision lead rail
Axes of motion 6 axes
Display mode LCD
Control system special controller for screwdriver machine
Program record capacity 9999
Programming interface teaching pandent
Air pressure 4~6kg cm2
Vltage AC220V
Dimensions 800X500X725mm
Weight 95kg



Automatic Screw Locking Machine Applications:

6 Axis Automatic Screw Locking Machine Air Blowing AC220V 0


Our Company Profile:

Established in 2005, located in Huizhou city, near Guangzhou and Shenzhen.

Winsmart has a driven, experienced, and knowledgeable team, providing extensive array of solutions for PCB depaneling and soldering, such as V-cut PCB separator, laser PCB depaneling, PCB router, PCB punching, hot bar soldering and soldering robot, etc. Above all, it takes pride in the quality and efficient service that it provides to customers, which is reflected by long-standing relationships across a diverse customer base.

We guarantee 12 months at least for all of our equipments, provide 7x24hours online service, oversea on-site installation and training is available to meet clients' needs.

Our PCB separators and soldering equipments are widely used in many industry manufacturing, such as LED lighting, mobile phone, computer, power source and cable, automotive, home electric appliances, toys, areospace, medical and other electronics industries.

We will continue to meet customers' requirements by supplying the excellent solution with unique technology and service!

6 Axis Automatic Screw Locking Machine Air Blowing AC220V 16 Axis Automatic Screw Locking Machine Air Blowing AC220V 2


Company History:

2008, Dongguan factory established, and start producing standard v-cut PCB separators and hot bar soldering machines.

2010, Our products are widely sold in local market.

2012, Start producing customized v-cut depaneling and PCB router.

2014, Expand our sales team for providing better service to more customers.

2015, Start manufacturing laser depaneling machines.

2017, Start manufacturing soldering robot and screwdriver machines.

2018, HK company established.
2019, Huizhou factory established, due to expansion.

2020, Business expansion again, products covering PCB depaneling, PCB soldering, screwdriver system, etc.

2021, Our machines cover all Chinese market and also popular in America, Europe, South Asia, East Asia, etc.
