Top Cutting Stand Alone Ionizer PCB Depaneling Router

Brand Name:	Winsmart
Model Number:	SMTRX
MOQ:	1 Set
Price:	USD20000-80000
Packaging Details:	Plywood case
Payment Terms:	T/T, L/C, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Color:

White

CE Approval:

Spindle:

Optional

Cutting Precision:

±0.05mm

Service:

Oversea Installation And Training Is Available

Name:

PCB Depaneling Router

Supply Ability:

100 Sets/Month

Highlight:

Ionizer PCB Depaneling Router

Top Cutting PCB Depaneling Router

Stand Alone PCB Depaneling Router Machine

Product Description

Stand Alone Ionizer PCB Depaneling Router Twin Tables and Top Cutting

PCB Router Features:

• Floor type double table cutting machine, with a speed of 100 mm / s and a positioning speed of 800 mm / s.

• High quality shaft system enables the system to accelerate and decelerate quickly, reduce synchronization time, improve productivity and maintain high accuracy.

• Use high quality hardware to ensure high rigidity and high performance.

• Automatic mark point positioning and correction system, real-time display of moving path and simulated route tracking, clear display at a glance, automatic alignment and correction function, high cutting accuracy

• All guide screws are covered to prevent dust and dirt from entering, to improve the service life and performance of the shaft.

• Avoid tin crack and parts damage caused by manual folding.

• Avoid the use of punching or folding, resulting in mechanical stress problems.

• Suitable for cutting arc and line of finished plate.

• It is suitable for cutting small pieces, such as mobile phone boards, PDA, PC interface card, etc.

PCB Router Specification:

Model Number	SMTRX
Machine Size	1200(L) x 1050(W) x 1400(H)mm
Voltage	380V/50Hz, 2.5KW
Max PCB Size	300x350mm (single table)
PCB Thickness	0.4-5mm
Feeding Mode	Manual
PCB Positioning	Customized fixture
Programming	Vision teaching, inline programming
Cutting Spindle	Optional
Cooling Type	Self cooling
Dust Collection Mode	Bottom/Top collection
Cutting Speed	1-100mm/s
Repeat Accuracy	±0.01mm
Routing Bit	0.8-3.0 Diameter, right rotation
Repeat Accuracy	±0.02mm
Control System	Industrial PC
Spindle	Optional
Motion Control	4 axis motion control board
Lead screw	C5 grinding screw lead
Camera	Germany imaging 40W greay camera
LCD	17 inch

PCB Router Package:

Top Cutting Stand Alone Ionizer PCB Depaneling Router 0

PCB Router Shipping Ways:

Tags:
