Product Details:
|
| PCB Thickness: | 0.8-1.2mm | PCB Material: | FR4 & MCPCB |
|---|---|---|---|
| Voltage: | 220V/110V | Warranty: | 1 Year |
| Full Automatic: | Yes | Name: | Multi Blade Pcb Depanelizer |
| High Light: | Multi Blade PCB Depanelizer Machine,Rigid PCB Depanelizer Machine,Inline PCB Depaneling Equipment |
||
Inline Multi Blade PCB Depanelizer For Rigid PCB Boards Separation
Multi Blade PCB Depanelizer Features:
Workable for “#”shape depaneling.
Horizontal and vertical depaneling is optional.
Blade set can be quickly changed.
Could connect PCB loader and PCB unloader to realize fully automated production to save labor.
Simple operation, workers can operate it after training.
Unique new blade design, lifetime should be increased by 1.5-2 times.
Safety: Sensor is used to ensure safe production.
Multi Blade PCB Depanelizer Specification:
| Blade dimension | Circular blade:¢80 ¢60mm Linear Blade: 356×43.5×6mm |
| PCB width | 300mm(could be customized) |
| Driven mode | Stepping / Servo motor(optional) |
| V-cut angel | >40° |
| Cutting speed | 300-500/s |
| Blade material | High speed steel |
| Air pressure | 0.5-0.8Mpa |
| Voltage | 220/110V |
| Dimension | 1250(1560)mm×800mm×1295mm |
| Packaging weight | 300kgs |
Operation Process:
Machine Horizontal and Vertical Cutting:
