AC220V Torque Control Electric Screwdriver Machine For Toys Manufacturing

AC220V Torque Control Electric Screwdriver Machine For Toys Manufacturing
AC220V Torque Control Electric Screwdriver Machine For Toys Manufacturing

Large Image :  AC220V Torque Control Electric Screwdriver Machine For Toys Manufacturing

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTSD112
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/Set
Packaging Details: Plywood case
Delivery Time: 5-8 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month

AC220V Torque Control Electric Screwdriver Machine For Toys Manufacturing

Color: Blue Working Stroke: 300x300x100mm
Power: 110V/220V Locking Speed: 2 Seconds Per Screw
Warranty: 1 Or 2 Years Name: Electric Torque Control Screwdriver
High Light:

AC220V Electric Screwdriver Machine


Torque Control Electric Screwdriver Machine


Toys Manufacturing Screwdriver Electric Machine

Electric Torque Control Screwdriver Machine for Toys Manufacturing



Robotic Screw Fastening System Features:

Desktop automatic tightening screw platform,Fully automated operation, save time, save labor, save costs, automatically tight screws.

Do not need to be equipped with an external computer, can do single operation, easy installation.

Versatility, replac the screw delivery module, suction nozzle, screw bit, it can be adapted to M1.0~ M4.0 screw.

At one product, the screw hole level can be different one the same side, it can do different.

Auto-sensing start function.


Hardware Introduction:

1. Motor axis number : 3 axis output.

2. Acceleration and deceleration performance : S-curve acceleration and deceleration mode,

acceleration and deceleration acceleration set independently; 10K speed refresh rate, make the

mechanical response better performance, less noise.

3. Pulse output frequency : 4MHz linear interpolation, 2MHz circular interpolation(including 3 axis

space circular interpolation), Using a motor which has 20000 pulses each turn as an example,

sufficient to meet the existing high-speed servo motor 5000 rpm/min requirements.

4. Home, Limit Input : Each motor has its own home-input, positive and negative limit-input, no need to take up the general input of programmable hardware resources.

5. Programmable input/output : it has 6 ways independent and dedicated programmable input and

output, all used optical isolation and each output current up to 500mA.

6. Supporting 3 bits digital number tube interface, can change and switch 1000 files range 0-999


7. Using the small key to adjust, In the absence of a teach box can also facilitate the realization of the

error due to the changing an electric screwdriver head correction.

8. Owning CAN bus, RS-232, Ethernet, can be customized to the special needs of special programs

9. Read/Write in U Disk : Use the FAT32 file system, no longer than 2G capacity U disk can not be

formatted to limit the FAT format.

10. Storage space : main board 256MV, can store 1000 processing files, each with 4000 program points; teach box 16MB, can store the boot screen, file, copy the file to each other in multiple machines is especially useful.

11. Screen of teach box : Use 480 X 272 pixels, 16 million true color 5-inch LCD screen, allowing the

operator menu interface and boot screen is much more abundant.

12. Work Voltage : DC 24V, current 2A.

13. Work environment : degree 0℃--45℃, humidity 40%--80%

14. Storage environment : degree -40℃--60℃, humidity 0%--95%


Software Introduction:

1. Three-dimensional linear interpolation, circular interpolation space (real hardware

three-dimensional instead of line fitting).

2. Programming point of the editor can be 30 times the "undo" "redo", to prevent misuse effectively .

3. Machining parameter setting is set up in the programming point, which can be realized in the same

process when different areas have different parameters.

4. In the return to the origin of the action when the axis back to the origin of the XYZ three axis at the

same time the origin of the capture action


Robotic Screw Fastening System Specifications:

Model SMTSD112
Moving range 300X*300Y*100Zmm
Processing range 270X*300Y*110Zmm
Repetitive accuracy ±0.02mm(X/Y/Z)
Fixture platform 1
Screw head 1
Applicable screw M1.0-M5.0
Screw conveying method Air blowing
Driving mode precision stepping motor+precision lead rail
Axes of motion 3 axes
Display mode LCD
Control system special controller for screwdriver machine
Program record capacity 9999
Programming interface teaching pandent
Air pressure 4~6kg cm2
Voltage AC220V
Dimensions 680X500X725mm
Weight 60kg

Robotic Screw Fastening System Suitable Screws:

AC220V Torque Control Electric Screwdriver Machine For Toys Manufacturing 0
