380V Manual Feeding Rotary Tables PCB Depaneling Machine

Brand Name:	Winsmart
Model Number:	SMTR288
MOQ:	1 Set
Price:	USD20000-80000
Packaging Details:	Plywood case
Payment Terms:	T/T, L/C, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Spindle:

Optional

Advantage:

Low Cost

Cutting Precision:

±0.05mm

Max PCB Size:

300x400mm

Routing Bit:

Left-hand

Cutting Speed:

1-100mm/s

Vacuum Cleaner:

Product Name:

PCB Depanel Machine

Supply Ability:

100 Sets/Month

Highlight:

Rotary Tables PCB Depaneling Machine

Manual Feeding PCB Depaneling Machine

380V PCB Router Machine

Product Description

PCB Depanel Machine Rotable Tables PCB Router For High Volume Boards

PCB Router Specification:

Model Number	SMTR288
Machine Size	1000(L) x 1244(W) x 1400(H)mm
Voltage	380V/50Hz, 3.5KW
Max PCB Size	300x400mm
PCB Thickness	0.4-6mm
Feeding Mode	Manual
PCB Positioning	Customized fixture
Programming	Vision teaching, inline programming
Cutting Spindle	SycoTec 60000rpm/min(standard)
Cooling Type	Self cooling
Dust Collection Mode	Bottom collection
Cutting Speed	1-100mm/s
Cutting Accuracy	±0.01mm
Routing Bit	0.8-3.0 Diameter, left rotation
Repeat Accuracy	±0.02mm
Vacuum Cleaner Size	625(L) x 600(W) x 1160(H)mm
Vacuum Cleaner Power	3HP, 2.2KW
Vacuum Cleaner Weight	130kgs
Active Protective Function	Safety light curtain
Security Door	Manual door
Programming Method	Camera assisted teaching

PCB Router Features:

1. Full electronic control, no air request

2. High stability, easy maintenance

3. Simple operation, short changeover time

4. Design for small and middle size PCBA

5. Rotary working tables

Warranty Period and Service Scope:

The equipment has been debugged and checked before leaving the factory, and the company will guarantee its use within the following conditions.

1. Warranty period

One year after leaving the factory, the main shaft runs 3500 hours.

2. Service scope

During the warranty period, the company will repair the fault free of charge, but the following conditions will not be covered by the warranty.

Use consumables and components not specified by the company.
Improper use or maintenance by operators.
Normal consumption of consumables.
Other natural disasters.
The color of equipment shell will fade naturally.
The change of heat and noise without affecting the normal operation of the equipment.

Suggestion: please check the instruction manual or contact our company if you encounter any problem that you don't understand in the actual process

Environment setting

1. The equipment should be installed in a ventilated and dry place. Do not install it in a place that is easy to corrode or flammable.

2. The equipment should not be installed in places exposed to sunlight and high heat.

3. Do not place the equipment in the place with strong vibration and easy collision.

Mechanical installation

1. Place the equipment in the designated position.

2. Adjust the level of the equipment with a level instrument, and then tighten the foot cup screw.

3. Connect the hose of the dust collector to the dust collecting port of the equipment.

4. Connect the power plug of the dust collector with the equipment to confirm the operation direction and dust collection effect. If it is reversed, replace any two of the three power lines.

5. Grounding requirements: please connect the equipment to the ground wire of distribution box separately, and do not connect with other equipment in series.

Power supply configuration

1. The standard input of the equipment is single-phase 220 V AC.

2. The equipment input 3-phase 380V AC needs to be equipped with transformer.

PCB Router Packaging:

Tags:

White PCB Depaneling Machine

4.5kg/cm2 Air Pressure PCB cutter machine

PC control PCB Depaneling Router Machine
