Product Details:
|
| Air Source: | 0.4MPa | PCB Material: | FR1, FR4, CEM1, CEM3, MCPCB |
|---|---|---|---|
| PCB Thickness: | 0.4-5mm | Blade: | 330mm(could Be Customized) |
| New: | 100% | Name: | Metal Core PCB Separator |
| High Light: | Metal Core PCB Separator Machine,300um Strain PCB Separator Machine,Pneumatic PCB Depaneler |
||
Metal Core PCB Separator Machine with 300um Strain Pneumatic PCB Depaneler
Features:
1. Separates boards up to 3.5mm thick.
2. Shears boards safely with parts as close as 0.5mm to the score line,including ceramic capacitors.
3. Operator foolproof! Panels cannot be inserted into the knives except on the score line.
4. Handles high components up to 70mm.
5. Blades can be re-sharpened.
6. Cutting stress is less than 300 uE.
7. Easy adjusting of distance between knives.
Principle:
It uses two linear blades to separate boards with less stress, like a scissor.
And operator cannot mis-feed boards.
It is widely used in modern V-score PCB industry, improve cutting effect to avoid component damage.
Specification:
| Model | SMTPD2 |
| Machine Dimension | 780x500x620mm |
| Max Cutting Length | 330mm |
| PCB Material | FR4, MCPCB, CEM, Copper Boards |
| Air Pressure | 0.4-0.7MPa |
| PCB Thickness | 0.3-3.5mm |
| Power | 110/220V |
| Machine Weight | 180kgs |
Our Service:
1. Lifetime technical support and 2 years warranty.
2. Free replacement or refund would be done in case of any quality problem.
3. Fast response/feedback within 12 hours
4. Engineers are available to be sent to do oversea installation and training.
5. Solid packaging to prevent damage from transportation.
