Product Details:
|
| Driven Mode: | Panasonic Motor | Soldering Head: | 1 |
|---|---|---|---|
| Customized Jig: | Yes | Power: | 220/110V |
| Working Stroke: | 300(X)x300(Y)x80(Z) | Name: | Soldering Robot |
| High Light: | Panasonic Motor PCB Soldering Robot,3 Axis PCB Soldering Robot,PLC PCB Soldering Robot |
||
Panasonic Motor PCB Soldering Robot Machine 3 Axis PLC Control
Robotic Soldering Machine Main Features:
1. Flexible and diverse soldering methods, with spot welding, drag welding (pull welding) and other functions.
2. The mechanical arms of the equipment are all aluminum profiles, which are not deformed, rusted and stable.
3. Device writing work program can be point-to-point, block-to-block copy, shorten the programming time.
4. The device has an automatic cleaning function, to a certain extent stabilize the quality of solder processing and extend the life of the soldering iron tip.
5. Multi-axis linkage manipulators, all adopt precision stepping motor drive and advanced motion control algorithms to effectively improve motion positioning accuracy and repeatability.
6. This machine is double head and single working place,we accept the double head and double working place and so on.
Robotic Soldering Machine Specifications:
| Model | SMTSR113 |
| Dimension | 880*700*830mm |
| Weight | 70Kg |
| Control | PLC |
| Programming | Teaching box |
| Driving mode | Stepper motor |
| Stroke | 300(X)x300(Y)x80(Z) |
| Soldering head | 1 |
| Repeatability | ±0.02mm(X/Y/Z) |
| Temp. Range | 0-500℃ |
| Solder Wire Spec | ￠0.3-1.6mm |
| Number of axes | 3 |
| Working pressure | 0.4~0.6Mpa(No water mist) |
| Power | AC110V/220V 300W |
| Display | LCD |
Robotic Soldering Machine Heater:
