6 Kg/Cm2 Automatic Screwdriver Machine 2 Fixture Platform XYZ Control

6 Kg/Cm2 Automatic Screwdriver Machine 2 Fixture Platform XYZ Control
6 Kg/Cm2 Automatic Screwdriver Machine 2 Fixture Platform XYZ Control

Large Image :  6 Kg/Cm2 Automatic Screwdriver Machine 2 Fixture Platform XYZ Control

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTSD227
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/Set
Packaging Details: Plywood case
Delivery Time: 5-8 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month

6 Kg/Cm2 Automatic Screwdriver Machine 2 Fixture Platform XYZ Control

Color: Blue Screw Size: M1.2-M5
Power: 110V/220V Usage: Screw Fastening
Type: Air Blowing Name: Automatic Screwdriver Machine
High Light:

6 kg/cm2 Automatic Screwdriver Machine


2 Fixture platform Automatic Screwdriver Machine


XYZ Control Auto Screw Dispenser

Robotic Screwdriver MachineAuto Screw Dispenser Dual Platform Automatic Screwdriver Machine



Automatic Screwdriver Machine Function:

Dual-platform blow-type automatic locking screw machine is composed of double Y-axis working platform + special feeder.
Taiwan Keli-speed electric batch + air-blowing feeding system + handheld teaching into a box, double Y-axis working platform.
According to the actual operation of the left and right control of the use of a single, continuous feeding, can provide screw counting function and anti-skid function, constant torque, with screw sliding and sliding lock detection.


Automatic Screwdriver Machine Classification:

Air blowing type, pneumatic driven

Vacuum suction type, motor driven


Automatic Screwdriver Machine Advantages:

1. Convenient: It can save a hand to hold the products and can save a positioning fixture if the product is small.

2. Fast: It can completely save the time for grasping and moving screws and the time of alignment and waiting.

3. Clean: It can avoid pollution of screws for saving the action of fetching screws by hand.


Automatic Screwdriver Machine Features:

1. With intelligent detection function, it can detect leak lock, floating lock, sliding screws, etc.
2. High versatility, the replacement screw delivery module can be adapted to the M1.0-M5 screw lock
3. High flexibility, standard universal clamp for a variety of models of screw locks.
4. Dual platform design, automatic alternate operation without downtime, fast speed and high efficiency
5. 2G storage space, which can store thousands of screwdriving programs, each program supports 9999 screwdriving instructions
6. The utility model adopts the vacuum suction screw method, has good versatility, overcomes the feature that the wind blow screw can not send the length to diameter ratio of 1.2, and overcomes the characteristics that the magnetic suction screw can not take the stainless steel screw.
7. The display adopts 320*240 high-resolution color screen and full English operation interface, easy to learn and use.


Automatic Screwdriver Machine Specifications:

Model SMTSD227
Moving range 500X*300Y1*300Y2*100Zmm
Processing range 180X*300Y*110Zmm
Repetitive accuracy ±0.02mm(X/Y/Z)
Fixture platform 2
Screw head 1
Applicable screw M1.2-M5.0
Screw conveying method Air blowing
Driving mode precision stepping motor+precision lead rail
Axes of motion 6 axes
Display mode LCD
Control system special controller for screwdriver machine
Program record capacity 9999
Programming interface teaching pandent
Air pressure 4~6kg cm2
Vltage AC220V
Dimensions 680X500X725mm
Weight 95kg


Robotic Screwdriver Machine Applications:

The automatic screwdriver machine is suitable for automated assembly in the electronics industry such as cameras, mobile phones, hard disks, keyboards, printers, computers, DVDs, home appliances, toys, appliances, communication equipment, electronic processing and assembly,etc. Automobile industry assembly, such as automotive motors, parts assembly, etc.


Robotic Screwdriver Machine Other Models

6 Kg/Cm2 Automatic Screwdriver Machine 2 Fixture Platform XYZ Control 0



Our Service:

1. Lifetime technical support and 2 years warranty.
2. Free replacement or refund would be done in case of any quality problem.
3. Fast response/feedback within 12 hours
4. Engineers are available to be sent to do oversea installation and training.
5. Solid packaging to prevent damage from transportation.
