Product Details:
|
| Current: | 50/60Hz | Type: | Soldering Machine |
|---|---|---|---|
| Fixture: | Customized Made | Condition: | Original New |
| Working Stroke: | 500(X)x300(Y1)x300(Y2)x80(Z)x360°(R) | Name: | LED Soldering Machine |
| High Light: | 60Hz Robotic Soldering Machine,50Hz Robotic Soldering Machine,Desktop Soldering Robot |
||
Dual Heads High Efficiency LED Soldering Machine Destop Soldering Robot
LED Soldering Machine Application:
Suitable for automotive electronics, digital, electronic, electro-acoustic, LCD, circuit board and other production industries, connectors, networks, transformers, cable, FPC / COF soldering, computer motherboards, CABLE, speakers and motors high quality soldering.
LED Soldering Machine Introduction:
Soldering Robot provides the best solution for soldering job on lead-free, heat dissipating PCB, and high thermal capacity components. It is suitable for all sorts of difficult soldering tasks and micro soldering process. It effectively improves the soldering quality and consistency. Besides, it saves 30% of the solder consumption comparing to manual soldering.
LED Soldering Machine Specifications:
| Model | SMTSR223 |
| Dimension | 680*500*720mm |
| Weight | 90Kg |
| Control | PLC |
| Programming | Teaching box |
| Driving mode | Stepper motor |
| Stroke | 300(X)x300(Y1)x300(Y2)x80(Z) |
| Soldering head | 2 |
| Repeatability | ±0.02mm(X/Y/Z) |
| Temp. Range | 0-550℃ |
| Solder Wire Spec | ￠0.3-1.6mm |
| Number of axes | 4 |
| Working pressure | 0.4~0.6Mpa(No water mist) |
| Power | AC110V/220V 300W |
| Display | LCD |
LED Soldering Machine Configuration:
1. Four-axis welding machine dual Y working platform
2. Handheld teach programmer
3. Heating controller
4. Broken tin controller
5. Solder pen assembly
6. Welding tip
7. Tin out components
8. Smoke purification filter system (optional)
LED Soldering Machine Packaging:
