Canon Cartridge Hot Bar Soldering Machine FPC To PCB Two Temperature Settings

Brand Name:	Winsmart
Model Number:	SMTS32
MOQ:	1 set
Price:	USD1-10000/Set
Packaging Details:	Plywood case
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Usage:

Pulse Heat

Color:

White

Voltage:

220V/110V

Temperature Accuracy:

Thermode Cooling:

Name:

Canon Cartridge Soldering Machine

Supply Ability:

200 sets per month

Highlight:

Canon Cartridge Hot Bar Soldering Machine

FPC To PCB SMT Soldering Machine

Floating Thermode Robotic Soldering Machine

Product Description

Canon Cartridge Soldering Machine Hot Bar Soldering Equipment

Hot Bar Soldering Machine Features:

Unique pulse heat technology provides fastest soldering head heating.

Programmable soldering temperature, heat-up rate and time duration for a wide range of products.

Thermocouple is fixed in close proximity to the working surface & the thermode, thus providing accurate temperature feedback control.

Closed Loop PID temperature control with clearly visible LED display.

Soldering time can be programmable and is triggered by temperature.

Floating thermode ensures consistent pressure and heat transfer between the thermode head and the parts to be joined.

Programmable pressure switch with LCD display for precise force control.

CCD camera system with magnification lens can be retrofitted for fine-pitch positioning.

Hot Bar Soldering Machine pecification:

Machine size	610×410×450mm
Working area	Max 150*150mm
Machine weight	62Kg
Working air pressure	0.6-0.8Mpa
Fixture quantity	1
Thermode head size	Max 40*3mm
Welding precision	pitch 0.2mm
Pressing time	1~99.9s
Temperature settings	RT~500℃ tolerance ±5℃
Welding pressure	1~20Kg
Temperature settings	Two
Working environment	10-60℃,40%-95%
Power supply	AC220V±10% 50HZ,2200W
Alignment mode	CCD + LCD Monitor
Feeding mode	Manual
Starting mode	Press start button
Rotation Platform	Cylinder control,tolerance<0.02mm

Hot Bar Soldering Machine Details:

Canon Cartridge Hot Bar Soldering Machine FPC To PCB Two Temperature Settings 0
