Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine

Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine
Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine
Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine

Large Image :  Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTAD5
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/set
Packaging Details: Plywood case
Delivery Time: 2-5 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month

Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine

Description
Mode: Automatic Usage: LED PCB Cutting
Cutting Length: 450mm Warranty: 2 Years
Power: 50W Name: LED PCB Cutting Machine
Highlight:

LED PCB Separator Machine

,

85kgs PCB Cutter Machine

,

PCB Separator Machine 85kgs

Automatic LED Pcb Cutting Machine / Pcb Cutter / Pcb Separator





LED PCB Cutting Machine Features:

1. Full automation,stable performance,easy operation,high safety and simple maintainence.

2. Uniquie shape,practical operation,and gorgeous appearance.

3. Cutting principle is based on Motor data transfer, blade moving to cut PCB.

4. Suitable for all V-CUT PCB board. PCB thickness:0.2-3.2mm, PCB v-cut thickness:0.2-2.0mm.

5. During cutting,it can effectively decrease physical strength to avoid welding spot cracking.

6. PCB remains still during cutting, thus to ensure personal safety.

7. Lower linear blade is used to fix the PCB v-cut, and upper circular blade moves to separate PCB.



LED PCB Cutting Machine Specification:

Model SMTAD5
Machine Dimension L940*W550*H460 mm
Max Cutting Length 450mm
PCB Material FR4, MCPCB
Cutting Speed 300mm/s or 500mm/s
PCB Thickness 0.6-2.0mm
Power 220/110V
Machine Weight 85kgs
Wooden Case Dimension 100x67x62cm
Gross Weight 90kgs



LED PCB Cutting Machine Details:

Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine 0



Packaging:

1. Fix the machine base on the wooden base by screws

2. Vacuum

3. Package into a wooden case

Automatic LED PCB Separator Machine , 85kgs PCB Cutter Machine 1

PCB Punching Machine Delivery Terms:

1. Ex-work/FOB/CIF/DDU, up to clients

2. Production leadtime: 7-15 days to customized make die tooling and test it with the punching machine.
