Automatic PCB Electronic Punching Machine Moveable Lower Die For Metal PCB Boards

Certification
China Winsmart Electronic Co.,Ltd certification
China Winsmart Electronic Co.,Ltd certification
Customer Reviews
The machine is on our production line being used and working well! It was a pleasure doing business with you!

—— Thomas

All your PCB depaneling machines are working very well, as we have been used them for more than 5 years! Qualified equipments! Excellent service!

—— Gary

I'm Online Chat Now

Automatic PCB Electronic Punching Machine Moveable Lower Die For Metal PCB Boards

Automatic PCB Electronic Punching Machine Moveable Lower Die For Metal PCB Boards
Automatic PCB Electronic Punching Machine Moveable Lower Die For Metal PCB Boards

Large Image :  Automatic PCB Electronic Punching Machine Moveable Lower Die For Metal PCB Boards

Product Details:
Place of Origin: China
Brand Name: Winsamrt
Certification: CE
Model Number: SMTP300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/set
Packaging Details: Plywood case
Delivery Time: 7-15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets

Automatic PCB Electronic Punching Machine Moveable Lower Die For Metal PCB Boards

Description
On-site Installation: Yes PCB Material: FR4, MCPCB
CE Certificate: Yes Packaging: Plywood Case
Precision: ±0.05mm Name: Automatic PCB Punching Machine
High Light:

MCPCB Electronic Punching Machine

,

Moveable Lower Die PCB Punching Machine

,

CEM PCB Punching Machine

Automatic PCB Punching Machine PCBA Punch For Metal PCB Boards



Function:

It is designed for PCB/FPC which is connected by points and stamp holes, has high efficiency precision stamping and punching effect. It is only guarantee slitting FPC, PCB deformation in current market.

Its minimum cutting precision is ±0.05mm for special slim PCBs. Max working area is 460*320mm.



PCB Punching Machine Features:

1.Depaneling PCB/FPC by means of punching dies, to avoid micro-cracks caused by manual.
2.Cast iron framework for rigidity. Punching dies are changeable. Easy set up of punching dies.
3.Moveable lower die for easy loading and unloadingPCB punch die| FPC die| PCB punch mold| FPC mould



PCB Punching Machine Specification:



Working area 460*320mm
Working pressure 0.45-0.7Mpa
Cutting precision ±0.05mm
Cycle time 7-15 seconds
Output 8T
PCB/FPC thickness 0.08-3.5MM
PCB/FPC material FPC, FR1, FR4, CEM-1, CEM-3, MCPCB
Cutting mode Punching
Punch fixture Die tooling(mold)
Working Property

LCD display, Automatically records the number of

processed products, automatic punching

Transmission port International standard
Operation Language English
Stroke 50MM
Mold height 170MM
Power 380/220V
Fuse 3A
Machine dimension 820x740x1750mm
Machine weight 680kgs



Punching Dies:

Automatic PCB Electronic Punching Machine Moveable Lower Die For Metal PCB Boards 0
