Flex PCB Punching Machine 380V 220V With Customized Punching Dies

Brand Name:	Winsamrt
Model Number:	SMTP300
MOQ:	1 set
Price:	USD1-10000/set
Packaging Details:	Plywood case
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Noise:

≤60dB

Working Area:

460x320mm

Output:

Type:

Pneumatic

Precision:

±0.05mm

Name:

PCB Punching Machine

Supply Ability:

100 sets

Highlight:

Flex PCB Punching Machine

PCB Punching Machine 380V

PCB Punching 220V

Product Description

Flex PCB Punching Machine FPC Punch With Customized Punching Dies

PCB Punching Machine Features:

Depaneling PCB/FPC by means of punching dies, to avoid micro-cracks caused by manual

Die toolings is changeable

Easy set up of punching dies

Loading and unloading PCBs is convenient

Easy operation, has safe protection system

Air cylinder driven

PCB Punching Machine Specification:

Working area	460*320mm
Working pressure	0.45-0.7Mpa
Cutting precision	±0.05mm
Cycle time	7-15 seconds
Output	8T
PCB/FPC thickness	0.08-3.5MM
PCB/FPC material	FPC, FR1, FR4, CEM-1, CEM-3, MCPCB
Cutting mode	Punching
Punch fixture	Die tooling(mold)
Working Property	LCD display, Automatically records the number of processed products, automatic punching
Transmission port	International standard
Operation Language	English
Stroke	50MM
Mold height	170MM
Power	380/220V
Fuse	3A
Machine dimension	820x740x1750mm
Machine weight	580kgs

PCB Punching Machine Die Tooling:

Flex PCB Punching Machine 380V 220V With Customized Punching Dies 0

PCB Punching Machine Delivery Terms:

1. Ex-work/FOB/CIF/DDU, up to clients

2. Production leadtime: 7-15 days to customized make die tooling and test it with the punching machine.
